Rigging Hardware

269 SKUs

Showing 241–269 of 269 SKUs

Stainless Steel Round Pad Eye with 4 Holes — dimension drawing

Stainless Steel Round Pad Eye with 4 Holes

Type 304 or 316 stainless steel9*90
Inquire
Red 322-pattern swivel hoist hook with safety latch, beside its drawing

Swivel Hoist Hook with Latch — 322 Pattern

3/4 t to 22 talloy 1 to 22 t; carbon 0.75 to 15 t
Inquire
Red 322-pattern swivel hoist hook, beside its dimension drawing

Swivel Hoist Hook — 322 Pattern

alloy 1 to 22 t; carbon 0.75 to 15 t3/4 t to 22 t
Inquire
Stainless Steel Eye Slip Hook with Latch — dimension drawing

Stainless Steel Eye Slip Hook with Latch

Type 304 or type 316 stainless steel17.8 to 53.4 kN
Inquire
Red 319-pattern shank hoist hook with safety latch, beside its drawing

Shank Hoist Hook with Latch — 319 Pattern

alloy 1 to 15 t; carbon 0.75 to 10 t3/4 t to 15 t
Inquire
Red 319-pattern shank hoist hook, beside its dimension drawing

Shank Hoist Hook — 319 Pattern

alloy 1 to 15 t; carbon 0.75 to 10 t3/4 t to 15 t
Inquire
Wood Lag Screw Ring Bolt — dimension drawing

Wood Lag Screw Ring Bolt

Zinc platedMild steel
Inquire
Swing Eye Bolt — DIN 444 — dimension drawing

Swing Eye Bolt — DIN 444

Zinc platedCarbon steel
Inquire
Stainless Steel Swing Eye Bolt — DIN 444 — dimension drawing

Stainless Steel Swing Eye Bolt — DIN 444

Stainless steel type 304/316Polished
Inquire
Stainless Steel Swing Eye Bolt — dimension drawing, uNC thread

Stainless Steel Swing Eye Bolt

PolishedStainless steel type 304 / 316 swing eye bolt
Inquire
Stainless steel US-type shoulder nut eye bolt with nut on a long shank

Stainless Steel Shoulder Nut Eye Bolt — US Type

Stainless steel 304 or 316, drop forged1/4″ × 2″ to 3/4″ × 6″
Inquire
Stainless Steel Shoulder Machinery Eye Bolt — G-279 Pattern — dimension drawing

Stainless Steel Shoulder Machinery Eye Bolt — G-279 Pattern

25.4 mm to 88.9 mmMachine polished /electrolytic polished
Inquire
Stainless Steel Shoulder Eye Bolt with Nut and Washer — UNC Thread — dimension drawing

Stainless Steel Shoulder Eye Bolt with Nut and Washer — UNC Thread

1/4″ to 7/8″Stainless steel 304/316 long shank eye bolt
Inquire
Stainless Steel Regular Nut Eye Bolt — G-291 Pattern — dimension drawing

Stainless Steel Regular Nut Eye Bolt — G-291 Pattern

500 lbs to 15200 lbsMachine polished /electrolytic polished
Inquire
Stainless Steel Long Shank Eye Bolt with Nut and Washer — dimension drawing, plain shank

Stainless Steel Long Shank Eye Bolt with Nut and Washer

Stainless steel 304/316 long shank eye boltPolished
Inquire
Stainless Steel Lag Eye Screw / Bolt — dimension drawing, lag eye screw

Stainless Steel Lag Eye Screw / Bolt

Stainless steel type 304 / 316 lag eye screwPolished
Inquire
Stainless Steel JIS B 1169 Eye Nut — dimension drawing, metric thread

Stainless Steel JIS B 1169 Eye Nut

PolishedType 304 or 316 stainless steel
Inquire
Fork Head Clevis Joint — DIN 71752 — dimension drawing

Fork Head Clevis Joint — DIN 71752

M4×0.7 to M16×2Mild steel / aluminum / stainless steel
Inquire

Questions we get asked

About this range

01Which shackle do I need — anchor (bow) or chain (dee)?
A chain (dee) shackle is for a straight, in-line pull. An anchor (bow) shackle has a rounder body that accepts more than one sling or a pull at an angle to the pin. For a permanent or long-term installation choose a bolt-type shackle, whose nut and cotter pin cannot unscrew in service; a screw-pin shackle suits rigging that is made and broken often.
02What is the difference between WLL, SWL and breaking load?
WLL — working load limit — is the most the manufacturer rates a part to carry in service. SWL, safe working load, is the older term and is sometimes set lower for a particular installation. The minimum breaking load is what the part withstood in test, several times its WLL, and it is never a working figure.
03Do the parts come with test certificates?
Yes. Each consignment ships with the manufacturer's test certificate. If your site needs more — third-party certification or witnessed proof testing — say so on the RFQ and we will confirm what we can arrange.
04Which rigging hardware is not meant for overhead lifting?
Anything without a published working load limit for lifting. On this shelf that typically includes cold shut and repair links, S hooks, most snap hooks and quick links, lag screw and wire-turned eye bolts, DIN 444 swing bolts, strap staples and lashing D rings, and commercial-grade shackles. These are made for fencing, lashing, light connecting and general duty. If a product page gives no WLL, or gives a lashing capacity instead, treat the item as not rated for lifting and use a rated shackle, hook, master link or lifting point instead.
05Can I mix US-pattern and European-pattern fittings in one rig?
Yes, provided every component is rated for the load it carries and the parts fit each other properly. Patterns differ in dimensions, so check the fit: a shackle pin must pass through a hook eye or lifting point without forcing, a master link must sit freely in the crane hook bowl, and no fitting should bear on another's tip or bind at an angle. The assembly is only as strong as its lowest-rated component, so rate the rig on that one, not on the heaviest part.
06Stainless, galvanised or alloy rigging hardware — which should I use?
Choose on rating first, then on environment. Grade 8 alloy fittings carry the highest rating for their size and suit heavy lifting; galvanised carbon steel is the general choice outdoors; stainless suits splash zones, food plant and architectural rigging where rust staining is unacceptable. Do not assume a stainless or galvanised part has the same WLL as an alloy part of the same nominal size — ratings are set by each maker for each material, and the size table on the product page shows them as separate rows.
07What are the types of rigging hardware?
The range covers G-209, G-213 and G-2130 pattern shackles, 320 and 331 pattern hooks, DIN 580 and JIS B 1168 eye bolts, master links, swivels and turnbuckles. Snap hooks, quick links, lifting points and pad eyes are also listed.
08What is rigging hardware used for?
Rigging hardware is the forged, cast and stainless fittings that join slings, chain and wire rope to a hook, a load or an anchor point. Indus supplies it from Dubai, UAE.
