How to choose
Size the bore for force, then fix the mounting
Push force is pressure times the full bore area: a 63 mm bore at 160 bar pushes about 50 kN, and pull force uses the bore area less the rod. Choose the rod for buckling strength over the stroke, then the mounting — clevis, foot, flange or trunnion — for how the load is applied. For a replacement, send the type code from the nameplate.
