Chemical transfer hose: how to read a compatibility chart properly

The liner decides everything. How compatibility charts work, why concentration and temperature change the answer, and what else has to be right before the hose is safe to use.

Written by
Ayush Bhatia, Director
Published
Updated
Reading
4 min · 3 sections
Share
An operator in chemical protective clothing connecting a composite transfer hose to a road tanker manifold on a bunded loading area
A chemical compatibility chart is only useful if you read it for the right temperature and concentration.

At a glance

Key takeaways

  1. The liner is the only part of the hose that meets the product. Everything about chemical suitability is a property of that material.
  2. Compatibility is not yes or no. Ratings assume a concentration, a temperature and a contact time, and change when any of those change.
  3. A hose that is compatible can still be the wrong choice if the couplings, gaskets or O-rings are not.
  4. On flammable transfer, electrical continuity through the whole assembly is a safety requirement and is verified periodically, not once.
  5. Composite hose earns its place here partly because it tends to weep before it fails outright.

Figures verified · Method only. No compatibility table is published here — use the liner manufacturer chart at your concentration and temperature.

Chemical hose selection goes wrong in a predictable way: someone checks the hose against the chemical, finds a green tick, and fits it with whatever couplings were on the shelf. The hose is then the only compatible part of the assembly.

/01Compatibility is conditional.

A compatibility chart is a statement about a material, a chemical, a concentration and a temperature — usually ambient, often at a stated concentration, and generally assuming intermittent rather than continuous contact. Change any of those and the rating can change with it. A liner rated for a dilute solution at 20 °C is not thereby rated for a concentrated one at 60 °C.

/02The whole assembly, not the hose.

A cut length of hydraulic hose held to camera, its inner tube swollen soft and glossy and closing down the bore
A swollen tube is what an incompatible fluid looks like once it has been in service. The chart exists to prevent this picture.
CHEMICAL HOSE ASSEMBLY · SPECIFICATION CHECKS6 checks

Before ordering

  1. Done

    Liner against the medium

    At your concentration and temperature, from the manufacturer chart. Not the hose "type" — the liner material.

    Who
    Engineer
    Tool
    Compatibility chart
  2. Done

    Couplings and gaskets

    Wetted metal and every seal must be compatible too. This is the step that is most often skipped.

    Who
    Engineer
    Tool
    Chart
  3. Done

    Temperature, both sides

    Medium temperature and Gulf ambient. A hose in direct sun runs well above shade temperature.

    Who
    Engineer
    Tool
    Process data
  4. Done

    Suction or delivery

    If it has to lift, it needs suction reinforcement. A delivery hose collapses under vacuum.

    Who
    Engineer
    Tool
    —
  5. Done

    Electrical continuity

    Required wherever the medium or atmosphere is flammable. Must be continuous through the couplings, not just the hose.

    Who
    Engineer
    Tool
    Continuity tester
  6. Done

    Documentation

    Test certificate and traceability, specified at order rather than requested afterwards.

    Who
    Procurement
    Tool
    —

The coupling point deserves emphasis because it is the common failure. A compatible hose fitted with an incompatible gasket fails at the gasket, and because the hose was the thing that got checked, the investigation tends to start in the wrong place. On transfer lines that coupling is very often a cam and groove coupling, and its gasket needs the same compatibility check as the hose liner.

/03Why composite is standard on transfer.

Composite hose is built from multiple unbonded film and fabric layers held between wire helices, and the films can be selected for the duty. Two consequences matter operationally: it is lighter for a given bore, which is significant on hoses handled by people rather than cranes, and it tends to weep before it fails outright rather than letting go suddenly. On flammable or aggressive transfer, a hose that warns you is worth a great deal. The end fittings are part of that design too: composite hose fittings are made for the construction and are not interchangeable with rubber-hose shanks.

The trade-off is handling. Composite is less tolerant of being crushed, dragged over a quay edge or driven over than a rubber hose of the same bore, so it rewards proper handling and storage in a way rubber will forgive.

What we list

Every listing on our Oil, Chemical & General-Purpose Hoses shelf:

Composite and chemical service

Common questions

How long does a chemical hose last?
There is no interval that survives contact with a real duty. Service life depends on the medium, the concentration, the temperature, how often it is drained and how it is handled between uses. Manage it by inspection and test rather than by a number.
Can I use the same hose for two different chemicals?
Only if the liner is compatible with both and there is no cross-contamination risk. Dedicating hoses per product and marking them is normal practice for good reasons.
Does electrical continuity need testing after installation?
It is verified periodically through the life of the assembly, not just at build. Continuity can be lost at a coupling without anything visible changing.
What about food-grade and potable duty?
Different question again — that is a compliance and traceability requirement as much as a material one. The certificate matters as much as the hose.

What next

  1. 01
  2. 02
  3. 03

    Where we supply this hose

    For chemical, food-grade, steam and water hose the certificate is most of what the buyer is actually purchasing, so it is prepared before dispatch rather than chased afterwards. We ship this class of hose from Dubai into plants audited against the same standards we quote to, with the documentation attached to the consignment and referenced on the invoice.

    GCC & Middle East

    North America & Caribbean

    Everything above ships from the same Dubai warehouse. If your destination is not listed, it is almost certainly still one we quote. See every export destination

Send us the medium and the conditions.

Chemical, concentration, temperature, pressure and whether it lifts. We will specify the hose, the couplings and the gaskets as one assembly.
