Multi-Purpose Mineral Oil & Air Hose 20 Bar
Medium pressure, electrically conductive fuel delivery hose for diesel, heating oils and petroleum including unleaded fuel for use across a variety of industries including automotive sector
Key features
- Application Family: oil-chemical-purpose
- Manufacturer Part Code: A125
- Inner Diameter Range: 6 mm to 25 mm
- Max Working Pressure: 20 bar
- Operating Temperature: From -40°C to +80°C
- Application Family
- oil-chemical-purpose
- Manufacturer Part Code
- A125
- Inner Diameter Range
- 6 mm to 25 mm
- Max Working Pressure
- 20 bar
- Operating Temperature
- From -40°C to +80°C
Product description
The Multi-Purpose Mineral Oil & Air Hose 20 Bar (part code A125) is a Oil / Chemical / General Purpose Hose from the Indus Hydraulics industrial hose range.
Application
Medium pressure, electrically conductive fuel delivery hose for diesel, heating oils and petroleum including unleaded fuel for use across a variety of industries including automotive sector
Construction
- Cover: Black smooth extruded, oil, abrasion, ozone and weather resistant NBR/SBR
- Lining / Tube: Black non-conductive NBR
- Reinforcement: High tensile strength textile plies
- Branding (printed on hose): INDUS LOGO, A125 MULTI-PURPOSE MINERAL
Performance
- Inner-diameter range: 6 mm to 25 mm
- Max working pressure: 20 bar
- Min burst pressure: 60 bar
- Min bend radius: 40-150 mm
- Weight: 0.17-0.73 kg/m
- Operating temperature: From -40°C to +80°C
- Safety factor: 3:1
Family context
Multi-purpose hoses for oil, fuel, mineral oil, and chemical transfer. Range covers tanker reeling, oil suction & delivery, and UHMWPE chemical hoses for aggressive media. EN 1761 / EN 12115 where applicable.
How to order
Specify (a) the inner diameter from the size range, (b) the assembly length, (c) end-fitting requirements, and (d) any special requirements such as Lloyd's certification or third-party witness testing. Indus engineering will confirm the assembly drawing on the RFQ.
Companion products
Pair with matching couplings and accessories (Cam & Groove, Boss steam couplings, hose clamps, Holedall permanently-attached fittings, hose tags, and Spiral Hose Guard / Fire Jacket protective sleeves) — full range available on quote.
Identification
| Parameter | Value |
|---|---|
| Application Family | oil-chemical-purpose |
| Manufacturer Part Code | A125 |
| Hose Branding (Printed) | INDUS LOGO, MULTI-PURPOSE MINERAL OIL & AIR HOSE 20 BAR |
Dimensions
| Parameter | Value |
|---|---|
| Inner Diameter Range | 6 mm to 25 mm |
| Min Bend Radius | 40-150 mm |
| Weight | 0.17-0.73 kg/m |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | 20 bar |
| Operating Temperature | From -40°C to +80°C |
| Safety Factor | 3:1 |
| Min Burst Pressure | 60 bar |
Construction
| Parameter | Value |
|---|---|
| Cover Material | Black smooth extruded, oil, abrasion, ozone and weather resistant NBR/SBR |
| Lining / Tube Material | Black non-conductive NBR |
| Reinforcement | High tensile strength textile plies |
Shipping & lead time
Sizes & part numbers
7 sizes| Indus part no. | Hose bore | O.D. (mm) | Min bend radius (mm) | Weight (kg/m) |
|---|---|---|---|---|
| IH-IH-A125-006 | 1/4" · DN6 | 14 | 40 | 0.17 |
| IH-IH-A125-008 | 5/16" · DN8 | 16 | 50 | 0.19 |
| IH-IH-A125-010 | 3/8" · DN10 | 18 | 60 | 0.23 |
| IH-IH-A125-013 | 1/2" · DN13 | 21 | 80 | 0.28 |
| IH-IH-A125-016 | 5/8" · DN16 | 25 | 100 | 0.38 |
| IH-IH-A125-019 | 3/4" · DN19 | 29 | 120 | 0.5 |
| IH-IH-A125-025 | 1" · DN25 | 36 | 150 | 0.73 |
O.D. — Outside diameter of the hose, which is what a clamp or a ferrule has to close on. Min bend radius — Tightest centreline radius the hose may be bent to at full working pressure. Weight — Weight of the hose per metre, as published.
Cut lengths and made-up assemblies are prepared in Dubai. Tell us the bore, the length and the ends you need.
