Industrial hose: a buyer’s guide by application, pressure, temperature and coupling

Industrial hose is the hose for everything that is not hydraulic power: water, air, oil, fuel, chemicals, food, steam, slurry and powder. On a hydraulic circuit, pressure is the hard constraint and everything else follows. On a transfer hose, the medium is the hard constraint — and a hose that is nominally strong enough can still be entirely unsuitable. This guide walks the decision in the order that avoids that mistake, and links to the detail on each part of it.

/01Six questions, in this order.

Our article on why industrial hose is not hydraulic hose explains the first question in more depth. The rest of this guide takes each in turn.

/02By application.

Each duty has its own article. Water: PVC or rubber suction hose and dewatering hose. Air: compressed air hose selection. Oil and fuel: oil suction and discharge hose and tanker loading and vapour recovery hose. Chemicals: UHMWPE chemical hose, composite hose and reading a compatibility chart. Food: food hose materials and food-grade compliance. Steam: steam hose safety. Abrasives: bulk material and sandblast hose.

/03The tube follows the medium.

The tube is the only part of the hose that touches the product, and its compound is the decision. SBR and natural rubber suit water, air and abrasive solids — natural rubber in particular resists sliding abrasion, which is why our bulk material hose uses it. Nitrile (NBR) resists oil and fuel, and our oil suction and delivery hoses use NBR rated for 50% aromatic hydrocarbons. EPDM handles hot water and steam but swells in oil. UHMWPE linings and composite films resist a very wide range of chemicals. For food, the same chemistry applies inside food-quality compounds: NBR for fats, EPDM for hot cleaning, platinum-cured silicone for the widest temperature range.

/04Pressure, vacuum and the safety factor.

Read three numbers off a listing or a layline: the working pressure, the vacuum rating if it is a suction hose, and the safety factor. Our water, air and oil suction and delivery hoses are built to 3:1; chemical, composite and silicone hoses to 4:1; steam hose to 10:1 — the reasons are in industrial hose safety factors. A suction hose prints its vacuum: 700 mmHg on A210, 0.93 bar on A430, 0.9 bar on A460. The print itself is decoded in reading an industrial hose layline.

Watch for ratings that change with size. PVC suction hose is rated per bore, falling from up to 12 bar on the smallest food hose to 2–3 bar at 6". Rubber suction hose holds one rating across its range. Couplings derate too: our cam and groove halves step from 250 psi at 2" to 75 psi at 6".

/05Temperature, inside and out.

A hose's temperature rating describes the medium, but in this region the outside matters as much. A dark hose on a site in summer can pass 55 °C on its surface carrying nothing warm — the upper limit of every PVC hose we list. Rubber water and air hoses run to +70 or +80 °C, oil hose to +100 °C, steam hose to +170 °C and our high-pressure steam hose to +210 °C. Silicone reaches +200 °C, PTFE +260 °C and corrugated metal hose +650 °C. Where heat comes from outside — a furnace, a steam range, an exhaust — choose for that, not for the fluid.

/06Static and conductivity.

Fuel, solvents and dry powders build electrostatic charge as they flow, and a discharge at a coupling can ignite vapour or dust. Hoses for those duties carry anti-static wires or a conductive tube: copper braids on our tanker reeling and UHMWPE hoses, anti-static wires on our oil and bulk material hoses, an anti-static tube on A361 and A101AS-T3. The path only works if the couplings are bonded to it and earthed. Test continuity coupling to coupling when the assembly is built and at every inspection; a broken bond looks exactly like a good hose.

/07Couplings and clamps.

The coupling is chosen by the equipment at the other end and by the region the hose will work in. Cam and groove dominates tanker, pump and chemical transfer; Storz, Guillemin, Barcelona and GOST are the symmetrical fire and water couplings of different countries; Bauer and ring lock join irrigation and slurry lines; universal claw couplings run site air; ground joints and EN 14423 clamps carry steam; EN 14420 fittings and DIN 2817 safety clamps hold chemical hose. Our industrial hose couplings guide covers every family we stock, and industrial hose clamps covers the part that most often decides the rating.

/08When rubber is the wrong construction.

Some duties rule out rubber altogether: sustained high temperature, cryogenic cold, fire exposure, permeation, or media that attack every elastomer. Those are the territory of metal hose — corrugated stainless and exotic alloy cores, braided for pressure — and of PTFE hose, the most chemically inert liner available.

/09Inspection and replacement.

Industrial hose fails at the couplings and at the bends more often than in the middle. Inspect for cover damage that exposes reinforcement, kinks and flattened sections, softening or swelling near the ends, a helix that has deformed, and couplings that have moved on their shanks. Re-tighten bolted clamps after the first pressurisation. Retire any hose that has been kinked, crushed or overheated, and any whose layline and tag have gone so it can no longer be identified. Steam hose deserves a defined replacement programme, because it deteriorates from the inside where inspection cannot reach.

Lay flat hose — the woven-jacket hose that rolls flat for transport and runs out in lengths up to 400 m — has its own guide: lay flat hose types, pressure ratings, sizing and couplings.
