High Pressure Red Saturated Steam Hose 18 Bar
High pressure saturated steam hose for high temperatures. Used in petrochemical plants/ refineries for maintenance and pipe insulation
Key features
- Application Family: industrial-steam
- Manufacturer Part Code: A230
- Inner Diameter Range: 13 mm to 51 mm
- Max Working Pressure: 18 bar
- Operating Temperature: From -40°C to +210°C. Intermittent 232°C
- Application Family
- industrial-steam
- Manufacturer Part Code
- A230
- Inner Diameter Range
- 13 mm to 51 mm
- Max Working Pressure
- 18 bar
- Operating Temperature
- From -40°C to +210°C. Intermittent 232°C
Product description
The High Pressure Red Saturated Steam Hose 18 Bar (part code A230) is a Industrial Steam Hose from the Indus Hydraulics industrial hose range.
Application
High pressure saturated steam hose for high temperatures. Used in petrochemical plants/ refineries for maintenance and pipe insulation
Construction
- Cover: Red mandrel wrap, ozone and weather resistant pin pricked EPDM. (Also available in black)
- Lining / Tube: Black EPDM
- Reinforcement: 2 ply multi stranded high tensile strength steel wires
- Branding (printed on hose): INDUS LOGO, A230 SUPER STEAM 18 BAR -
Performance
- Inner-diameter range: 13 mm to 51 mm
- Max working pressure: 18 bar
- Min burst pressure: 180 bar
- Min bend radius: 130-500 mm
- Weight: 0.53-2.20 kg/m
- Operating temperature: From -40°C to +210°C. Intermittent 232°C
- Safety factor: 10:1
Family context
Saturated-steam transfer hoses with red or black EPDM cover, steel-wire reinforcement, and high-temperature EPDM tube. 7-18 bar saturated steam service. BS 5342 / EN ISO 6134 type 2 class A.
How to order
Specify (a) the inner diameter from the size range, (b) the assembly length, (c) end-fitting requirements, and (d) any special requirements such as Lloyd's certification or third-party witness testing. Indus engineering will confirm the assembly drawing on the RFQ.
Companion products
Pair with matching couplings and accessories (Cam & Groove, Boss steam couplings, hose clamps, Holedall permanently-attached fittings, hose tags, and Spiral Hose Guard / Fire Jacket protective sleeves) — full range available on quote.
Identification
| Parameter | Value |
|---|---|
| Application Family | industrial-steam |
| Manufacturer Part Code | A230 |
| Hose Branding (Printed) | INDUS LOGO, A230 SUPER STEAM 18 BAR - |
Dimensions
| Parameter | Value |
|---|---|
| Inner Diameter Range | 13 mm to 51 mm |
| Min Bend Radius | 130-500 mm |
| Weight | 0.53-2.20 kg/m |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | 18 bar |
| Min Burst Pressure | 180 bar |
| Operating Temperature | From -40°C to +210°C. Intermittent 232°C |
| Safety Factor | 10:1 |
Construction
| Parameter | Value |
|---|---|
| Cover Material | Red mandrel wrap, ozone and weather resistant pin pricked EPDM. (Also available in black) |
| Lining / Tube Material | Black EPDM |
| Reinforcement | 2 ply multi stranded high tensile strength steel wires |
Shipping & lead time
Sizes & part numbers
6 sizes| Indus part no. | Hose bore | O.D. (mm) | Min burst (bar) | Min bend radius (mm) | Weight (kg/m) | Working pressure (bar) |
|---|---|---|---|---|---|---|
| IH-IH-A230-013 | 1/2" · DN13 | 25 | 180 | 130 | 0.53 | 18 |
| IH-IH-A230-019 | 3/4" · DN19 | 32 | 180 | 190 | 0.76 | 18 |
| IH-IH-A230-025 | 1" · DN25 | 38 | 180 | 250 | 1 | 18 |
| IH-IH-A230-032 | 1-1/4" · DN32 | 46 | 180 | 320 | 1.3 | 18 |
| IH-IH-A230-038 | 1-1/2" · DN38 | 54 | 180 | 380 | 1.65 | 18 |
| IH-IH-A230-051 | 2" · DN51 | 67 | 180 | 500 | 2.2 | 18 |
O.D. — Outside diameter of the hose, which is what a clamp or a ferrule has to close on. Min burst — Minimum burst pressure. A test figure, never a working limit — never select on it. Min bend radius — Tightest centreline radius the hose may be bent to at full working pressure. Weight — Weight of the hose per metre, as published.
Working pressure is the published rating for the hose itself. A made-up assembly is limited by its lowest-rated part, so check it against the coupling, the clamp or ferrule, and the temperature you are running at.
Cut lengths and made-up assemblies are prepared in Dubai. Tell us the bore, the length and the ends you need.
