JIC Male 37° Cone Long Hose Fitting
JIC Male 37° Cone Long — 37° cone seat (JIC), metal-to-metal, in 20 sizes from -04.
Key features
- Fitting Configuration: straight
- Thread Form: 1.1/16"×12 to 9/16"×18
- Sealing Form: 37° cone seat (JIC), metal-to-metal
- Nominal Size Range: -04 to -24
- Fitting Configuration
- straight
- Thread Form
- 1.1/16"×12 to 9/16"×18
- Sealing Form
- 37° cone seat (JIC), metal-to-metal
- Nominal Size Range
- -04 to -24
Product description
The JIC Male 37° Cone Long Hose Fitting is a hydraulic hose fitting with 37° cone seat (JIC), metal-to-metal.
The long version of the JIC male. Same thread and seat as the standard body, with more length between the seat and the hose — for reaching past a bracket or a manifold face.
Construction
- Configuration: straight
- Thread: 1.1/16"×12 to 9/16"×18
- Sealing form: 37° cone seat (JIC), metal-to-metal
- Gender: male
- Material: carbon steel, zinc-plated and Cr3+ passivated (316 stainless on request)
Sizes
20 sizes, hose bore -04 to -24, threads 1.1/16"×12 to 9/16"×18. The full size and dimension table is on this page.
How to order
Quote the Indus part number for the size you need. Tell us the hose grade and bore and we will include the matching crimp ferrule — the ferrule follows the hose, not the fitting. Indus crimps and pressure-tests assemblies before dispatch.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | straight |
| Thread Form | 1.1/16"×12 to 9/16"×18 |
| Sealing Form | 37° cone seat (JIC), metal-to-metal |
| Thread Gender | male |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | -04 to -24 |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel (316 stainless on request) |
| Surface Treatment | Zinc-plated, Cr3+ passivated, RoHS-compliant |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | SAE J514, ISO 8434-2 |
Shipping & lead time
Sizes & part numbers
20 sizes| Indus part no. | Hose bore | Size | S1 (mm) | A (mm) | C (mm) |
|---|---|---|---|---|---|
| IH-JIC-MAL-37-LONG-0405 | -04 · 1/4" · DN6 | 1/2"×20 | 19 | 43 | 30.5 |
| IH-JIC-MAL-37-LONG-0404 | -04 · 1/4" · DN6 | 7/16"×20 | 17 | 43 | 30.5 |
| IH-JIC-MAL-37-LONG-0406 | -04 · 1/4" · DN6 | 9/16"×18 | 22 | 47 | 32.5 |
| IH-JIC-MAL-37-LONG-0505 | -05 · 5/16" · DN8 | 1/2"×20 | 19 | 43 | 30.5 |
| IH-JIC-MAL-37-LONG-0506 | -05 · 5/16" · DN8 | 9/16"×18 | 22 | 47 | 32.5 |
| IH-JIC-MAL-37-LONG-0608 | -06 · 3/8" · DN10 | 3/4"×16 | 24 | 51 | 36.5 |
| IH-JIC-MAL-37-LONG-0610 | -06 · 3/8" · DN10 | 7/8"×14 | 30 | 56.5 | 40 |
| IH-JIC-MAL-37-LONG-0606 | -06 · 3/8" · DN10 | 9/16"×18 | 22 | 47 | 32.5 |
| IH-JIC-MAL-37-LONG-0812 | -08 · 1/2" · DN12 | 1.1/16"×12 | 36 | 63 | 44.5 |
| IH-JIC-MAL-37-LONG-0808 | -08 · 1/2" · DN12 | 3/4"×16 | 24 | 51.5 | 36.5 |
| IH-JIC-MAL-37-LONG-0810 | -08 · 1/2" · DN12 | 7/8"×14 | 30 | 57 | 40 |
| IH-JIC-MAL-37-LONG-1012 | -10 · 5/8" · DN16 | 1.1/16"×12 | 36 | 64 | 44.5 |
| IH-JIC-MAL-37-LONG-1010 | -10 · 5/8" · DN16 | 7/8"×14 | 30 | 58 | 40 |
| IH-JIC-MAL-37-LONG-1212 | -12 · 3/4" · DN20 | 1.1/16"×12 | 36 | 64 | 44.5 |
| IH-JIC-MAL-37-LONG-1216 | -12 · 3/4" · DN20 | 1.5/16"×12 | 41 | 66 | 44.5 |
| IH-JIC-MAL-37-LONG-1616 | -16 · 1" · DN25 | 1.5/16"×12 | 41 | 67 | 44.5 |
| IH-JIC-MAL-37-LONG-1620 | -16 · 1" · DN25 | 1.5/8"×12 | 50 | 70.5 | 45.7 |
| IH-JIC-MAL-37-LONG-2020 | -20 · 1.1/4" · DN32 | 1.5/8"×12 | 50 | 71.2 | 45.7 |
| IH-JIC-MAL-37-LONG-2024 | -20 · 1.1/4" · DN32 | 1.7/8"×12 | 55 | 71.5 | 46 |
| IH-JIC-MAL-37-LONG-2424 | -24 · 1.1/2" · DN40 | 1.7/8"×12 | 55 | 71.5 | 46 |
S1 — Dimension S1 on the manufacturer dimension drawing. A — Dimension A on the manufacturer dimension drawing. C — Dimension C on the manufacturer dimension drawing. Ask us for the dimension drawing if you need it stamped.
Every size is available in 316 stainless steel on request — add “-SS” to the part number when you enquire.
What is the sealing form?▾
What sizes are available?▾
What is the maximum working pressure?▾
Which ferrule pairs with this fitting?▾
Is stainless steel available?▾
Can Indus crimp the assembly?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
The same part, in the designations used across European and Gulf trade catalogues.
- de
- gerade JIC Außengewinde 37° Bördel Schlaucharmatur
- fr
- mâle JIC cône 37° embout de flexible
- es
- macho JIC cono 37° racor de manguera
- it
- maschio JIC cono 37° raccordo per tubo flessibile
