ISO 16028 Flush Face Hydraulic Quick Coupler
Premium ISO 16028 flush-face quick coupler — push-to-connect, dual flush-face valving for minimal fluid loss and zero air inclusion at disconnect. The volume modern hydraulic OEM coupler.
Key features
- Series: QC-16028
- Interchange Standard: ISO 16028
- Application Class: Hydraulic
- Valving: Flush Face (No-Spill)
- Connection Method: Push-to-Connect
- Flush Face / No-Spill
- Maximum Operating Pressure: 300 bar
- Series
- QC-16028
- Interchange Standard
- ISO 16028
- Application Class
- Hydraulic
- Valving
- Flush Face (No-Spill)
- Available Body Sizes
- 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
- Connection Method
- Push-to-Connect
Product description
The ISO 16028 Flush Face Hydraulic Quick Coupler is a hydraulic quick-disconnect coupling in the Indus QC-16028 range. Premium ISO 16028 flush-face quick coupler — push-to-connect, dual flush-face valving for minimal fluid loss and zero air inclusion at disconnect. The volume modern hydraulic OEM coupler.
Working pressure to 300 bar (4351 psi) at the smallest body size, with minimum burst pressure of 1200 bar. Push-to-Connect connection — flush face (no-spill) variant.
Construction & features
- Interchange standard: ISO 16028
- Connection method: Push-to-Connect
- Valving: Flush Face (No-Spill)
- Interchanges with: Parker FEM (ISO 16028), Faster FFI, Stucchi APM, Snap-tite 78, HTMA-interchangeable in 3/8" size, Eaton FD89
Available variants — specify in your RFQ
Indus supplies the full QC-16028 range. Specify the configuration that matches your hose end and operating envelope and we will quote against it.
- Coupling halves: Male, Female, Complete Set, Dust Cap (PVC), Dust Plug (PVC)
- Body sizes: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
- Body materials: Carbon Steel (zinc trivalent chromate plated)
- Seal materials: Buna-N (with anti-extrusion Teflon seal)
- Port thread types: Female NPT, Female BSP, Female SAE O-ring
Performance
- Maximum operating pressure: 300 bar (4351 psi) at the smallest size; derates with diameter
- Minimum burst pressure: 1200 bar (17405 psi)
- Rated flow (largest size): up to 379 L/min
- Vacuum rating: 28 in./Hg
- Operating temperature range: -40°C to +100°C (varies by seal compound; specify in RFQ)
Replacing an existing coupling?
This coupler is dimensionally interchangeable with Eaton FD89, and with Parker FEM (ISO 16028), Faster FFI, Stucchi APM, Snap-tite 78, HTMA-interchangeable in 3/8" size. If you are matching an existing fleet, quote the coupling you are replacing on the RFQ and we will confirm the mating half before you order.
How to order
Confirm the coupling half (male / female / complete set / dust cap), body size, port thread type and size, seal compound and body material. Indus quotes with material certification on request, and air-freight or sea-freight to the UAE and wider GCC. Standard lead time 14 days from order; stocked configurations ship the same week.
Companion products
Indus also supplies the matching dust caps, dust plugs and seal repair kits for this series — add them to the same RFQ. For a hose assembly terminated with this coupler, request a complete assembly quote and we will supply it tested at 1.5× working pressure with a witness-test certificate.
Identification
| Parameter | Value |
|---|---|
| Series | QC-16028 |
| Interchange Standard | ISO 16028 |
| Application Class | Hydraulic |
| Valving | Flush Face (No-Spill) |
Variants
| Parameter | Value |
|---|---|
| Available Body Sizes | 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2" |
| Available Body Materials | Carbon Steel (zinc trivalent chromate plated) |
| Available Seal Materials | Buna-N (with anti-extrusion Teflon seal) |
| Available Port Thread Types | Female NPT, Female BSP, Female SAE O-ring |
| Available Coupling Halves | Male, Female, Complete Set, Dust Cap (PVC), Dust Plug (PVC) |
Construction
| Parameter | Value |
|---|---|
| Connection Method | Push-to-Connect |
| Flush Face / No-Spill | yes |
| Connect Under Pressure | no |
Performance
| Parameter | Value |
|---|---|
| Maximum Operating Pressure | 300 bar |
| Minimum Burst Pressure | 1200 bar |
| Rated Flow (Largest Size) | 379 L/min |
| Vacuum Rating | 28 in./Hg |
| Operating Temperature Min | -40 °C |
| Operating Temperature Max | 100 °C |
Compliance
| Parameter | Value |
|---|---|
| Interchanges With (Competitor Brands) | Parker FEM (ISO 16028), Faster FFI, Stucchi APM, Snap-tite 78, HTMA-interchangeable in 3/8" size, Eaton FD89 |
Shipping & lead time
Sizes & part numbers
9 sizes| Indus part no. | End 1 | End 2 |
|---|---|---|
| IH-QD-FF-04F-04FP | 1/4" ISO 16028 female coupler | 1/4" NPTF female (1/4-18) |
| IH-QD-FF-06F-06FP | 3/8" ISO 16028 female coupler | 3/8" NPTF female (3/8-18) |
| IH-QD-FF-06F-08FP | 3/8" ISO 16028 female coupler | 1/2" NPTF female (1/2-14) |
| IH-QD-FF-08F-06FP | 1/2" ISO 16028 female coupler | 3/8" NPTF female (3/8-18) |
| IH-QD-FF-08F-08FP | 1/2" ISO 16028 female coupler | 1/2" NPTF female (1/2-14) |
| IH-QD-FF-08F-12FP | 1/2" ISO 16028 female coupler | 3/4" NPTF female (3/4-14) |
| IH-QD-FF-10F-12FP | 5/8" ISO 16028 female coupler | 3/4" NPTF female (3/4-14) |
| IH-QD-FF-12F-12FP | 3/4" ISO 16028 female coupler | 3/4" NPTF female (3/4-14) |
| IH-QD-FF-16F-16FP | 1" ISO 16028 female coupler | 1" NPTF female (1-11.5) |
End 1 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. End 2 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. Ask us for the dimension drawing if you need it stamped.
What is the Indus QC-16028 range used for?▾
What is the maximum working pressure?▾
What sizes are available?▾
What seal and body materials are available?▾
What port thread options are available?▾
Does this coupling connect under pressure?▾
Will this replace the coupling already on my machine?▾
What is the typical lead time?▾
