Horizontal Lifting Clamp with Locking Device — Type TMS
Horizontal Lifting Clamp with Locking Device, Type TMS, in 5 sizes, 1 t to 10 t. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Horizontal lifting clamp
- Pattern / standard: TMS type
- Size range: 1 t to 10 t
- Working load limit: 1 to 10 t
- Size range
- 1 t to 10 t
- Working load limit
- 1 to 10 t
- Material
- Carbon steel
- Finish
- Painted
Product description
Horizontal lifting clamp with a spring-loaded locking mechanism that keeps the jaw closed on the load, and a handle for opening it. For plate, structural bars and construction steel.
Sizes and ratings
5 sizes, 1 t to 10 t. Rated load 1 to 10 t. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Horizontal clamps lift in pairs or sets, spaced along the plate so it stays level. Choose by rated load. The table gives the rated load as the manufacturer publishes it; confirm on the quotation whether the figure is for one clamp or for the set, and work to the load marked on the clamp.
Ordering
Quote the Indus part number from the size table, or send the size and working load you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Horizontal lifting clamp |
| Pattern / standard | TMS type |
| Sizes | 5 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 1 t to 10 t |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 1 to 10 t |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
| Finish | Painted |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
5 sizes| Indus part no. | Size | WLL (t) | Weight (kg) |
|---|---|---|---|
| IH-LR-LC-TMS-1T | 1 t | 1 | 14 |
| IH-LR-LC-TMS-2T | 2 t | 2 | 16 |
| IH-LR-LC-TMS-3T | 3 t | 3 | 24 |
| IH-LR-LC-TMS-5T | 5 t | 5 | 36 |
| IH-LR-LC-TMS-10T | 10 t | 10 | 90 |
Size — Nominal size as the manufacturer states it. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What sizes does the horizontal lifting clamp with locking device come in?▾
What is the working load limit?▾
Is the rated load for one clamp or for a pair?▾
Do the parts come with a test certificate?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
The same part, in the designations used across European and Gulf trade catalogues.
- de
- Schlauchschelle
- fr
- collier de serrage
- es
- abrazadera de manguera
- it
- fascetta stringitubo
From the blog
Written about this part
Engineers viewing this also looked at
Universal Plate Lifting Clamp
Lifting Beam Clamp
Vertical Plate Lifting Clamp — Type CDH
Horizontal Plate Lifting Clamp
Horizontal Plate Lifting Clamp — Type L
Horizontal Lifting Clamp for Steel Sections — Type LC
Horizontal Plate Lifting Clamp with Roller — Type PDQ
