2-1/2" Glycerin-Filled Panel Gauge, Front Flange, 1/4" Back Mount
2-1/2" Glycerin-Filled Panel Gauge, Front Flange, 1/4" Back Mount: brass internals, ASME B40.100, 6 ranges from vacuum and 0–100 psi up to 0–5,000 psi.
Key features
- Body Configuration: 2-1/2" pressure gauge, centre back mount with front flange
- Port A Thread: 1/4" connection, centre back mount with front flange
- Nominal Size Range: 2-1/2" dial
- Body Configuration
- 2-1/2" pressure gauge, centre back mount with front flange
- Port A Thread
- 1/4" connection, centre back mount with front flange
Product description
A 2-1/2" dial pressure gauge with a stainless steel case and bezel and copper-alloy (brass) internals, filled with glycerin to damp pointer flutter from pump pulsation and vibration. Front flange screws to the face of a panel cut-out, connection at the centre of the back.
Specification
- Dial: 2-1/2", dual scale psi and bar
- Case and bezel: stainless steel
- Internals: copper alloy (brass) Bourdon tube and socket
- Lens: polycarbonate
- Fill: glycerin
- Connection: 1/4", centre back mount with front flange
- Standard: ASME B40.100
Ranges
6 ranges, vacuum and 0–100 psi up to 0–5,000 psi. The Sizes & Part Numbers tab lists every scale.
Choosing a range
Pick a scale whose full reading is about twice the normal working pressure, so the pointer sits mid-dial and spikes stay on the scale. Brass internals suit oil, water and air; for corrosive media ask for a stainless-internal gauge.
How to order
Quote the Indus part number, or send the range, mounting and connection thread. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Body Configuration | 2-1/2" pressure gauge, centre back mount with front flange |
Port A
| Parameter | Value |
|---|---|
| Port A Thread | 1/4" connection, centre back mount with front flange |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 2-1/2" dial |
Construction
| Parameter | Value |
|---|---|
| Material | stainless steel case and bezel, brass internals, polycarbonate lens, glycerin fill |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | ASME B40.100 |
Shipping & lead time
Sizes & part numbers
6 sizes| Indus part no. | Range |
|---|---|
| IH-GA-204L-254A | 30"Hg vacuum – 0 |
| IH-GA-204L-254E | 0 – 100 psi |
| IH-GA-204L-254G | 0 – 200 psi |
| IH-GA-204L-254K | 0 – 600 psi |
| IH-GA-204L-254P | 0 – 3,000 psi |
| IH-GA-204L-254R | 0 – 5,000 psi |
Every size is available in 316 stainless steel on request — add “-SS” to the part number when you enquire.
Why is it glycerin filled?▾
What media can it measure?▾
What thread is the connection?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
