Tompkins FF2501 Male ORFS × Male NPTF 90° Elbow
Tompkins FF2501 male ORFS × male NPTF 90° elbow, carbon steel: 17 sizes, 9/16-18 ORFS to 2-12 ORFS.
Key features
- Fitting Configuration: 90° Elbow
- Nominal Size Range: 9/16-18 ORFS to 2-12 ORFS
- Fitting Configuration
- 90° Elbow
Product description
The Tompkins FF2501 is a carbon steel male ORFS × male NPTF 90° elbow from Tompkins Industries' hydraulic adapter range, in 17 sizes from 9/16-18 ORFS to 2-12 ORFS.
Specification
- Configuration: Male ORFS × Male NPTF 90° Elbow (90° elbow)
- Material: Carbon steel
- End A: Male ORFS
- End B: Male NPTF
- Sizes: 17
Sizes and part numbers
The Sizes & Part Numbers tab lists each Tompkins number with its thread. Tompkins numbers give the style code, then the dash size of each end in the order the ends are named.
Choosing and fitting
Match each end to the port or tube it meets: JIC 37° and SAE O-ring boss share UNF threads at the same dash size but seal differently (37° flare vs an O-ring on the boss), and ORFS seals on an O-ring in the face. Check the thread before installing; never mix sealing types on one joint.
How to order
Quote the Tompkins part number, or the end types and dash sizes. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | 90° Elbow |
| Style | Male ORFS × Male NPTF 90° Elbow |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 9/16-18 ORFS to 2-12 ORFS |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
Shipping & lead time
Sizes & part numbers
17 sizes| Tompkins part no. | End 1 | End 2 |
|---|---|---|
| FF2501-04-02 | 9/16-18 ORFS | 1/8-27 NPTF |
| FF2501-04-04 | 9/16-18 ORFS | 1/4-18 NPTF |
| FF2501-06-04 | 11/16-16 ORFS | 1/4-18 NPTF |
| FF2501-06-06 | 11/16-16 ORFS | 3/8-18 NPTF |
| FF2501-06-08 | 11/16-16 ORFS | 1/2-14 NPTF |
| FF2501-08-06 | 13/16-16 ORFS | 3/8-18 NPTF |
| FF2501-08-08 | 13/16-16 ORFS | 1/2-14 NPTF |
| FF2501-08-12 | 13/16-16 ORFS | 3/4-14 NPTF |
| FF2501-10-08 | 1-14 ORFS | 1/2-14 NPTF |
| FF2501-10-12 | 1-14 ORFS | 3/4-14 NPTF |
| FF2501-12-08 | 1-3/16-12 ORFS | 1/2-14 NPTF |
| FF2501-12-12 | 1-3/16-12 ORFS | 3/4-14 NPTF |
| FF2501-12-16 | 1-3/16-12 ORFS | 1-11½ NPTF |
| FF2501-16-12 | 1-7/16-12 ORFS | 3/4-14 NPTF |
| FF2501-16-16 | 1-7/16-12 ORFS | 1-11½ NPTF |
| FF2501-20-20 | 1-11/16-12 ORFS | 1-1/4-11½ NPTF |
| FF2501-24-24 | 2-12 ORFS | 1-1/2-11½ NPTF |
End 1 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. End 2 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. Ask us for the dimension drawing if you need it stamped.
What sizes is the Tompkins FF2501 made in?▾
Is it carbon steel or stainless?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
