Tompkins FF6504 Male JIC 37° × Female ORFS Swivel Adapter
Tompkins FF6504 male JIC 37° × female ORFS swivel adapter, carbon steel: 6 sizes, 7/16-20 JIC to 1-5/16-12 JIC.
Key features
- Fitting Configuration: Straight
- Nominal Size Range: 7/16-20 JIC to 1-5/16-12 JIC
- Fitting Configuration
- Straight
Product description
The Tompkins FF6504 is a carbon steel male JIC 37° × female ORFS swivel adapter from Tompkins Industries' hydraulic adapter range, in 6 sizes from 7/16-20 JIC to 1-5/16-12 JIC.
Specification
- Configuration: Male JIC 37° × Female ORFS Swivel Adapter (straight)
- Material: Carbon steel
- End A: Male JIC 37°
- End B: Female ORFS Swivel
- Sizes: 6
Sizes and part numbers
The Sizes & Part Numbers tab lists each Tompkins number with its thread. Tompkins numbers give the style code, then the dash size of each end in the order the ends are named.
Choosing and fitting
Match each end to the port or tube it meets: JIC 37° and SAE O-ring boss share UNF threads at the same dash size but seal differently (37° flare vs an O-ring on the boss), and ORFS seals on an O-ring in the face. Check the thread before installing; never mix sealing types on one joint.
How to order
Quote the Tompkins part number, or the end types and dash sizes. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | Straight |
| Style | Male JIC 37° × Female ORFS Swivel Adapter |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 7/16-20 JIC to 1-5/16-12 JIC |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
Shipping & lead time
Sizes & part numbers
6 sizes| Tompkins part no. | End 1 | End 2 |
|---|---|---|
| FF6504-04-04 | 7/16-20 JIC | 9/16-18 ORFS |
| FF6504-06-06 | 9/16-18 JIC | 11/16-16 ORFS |
| FF6504-08-08 | 3/4-16 JIC | 13/16-16 ORFS |
| FF6504-10-10 | 7/8-14 JIC | 1-14 ORFS |
| FF6504-12-12 | 1-1/16-12 JIC | 1-3/16-12 ORFS |
| FF6504-16-16 | 1-5/16-12 JIC | 1-7/16-12 ORFS |
End 1 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. End 2 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. Ask us for the dimension drawing if you need it stamped.
