Tompkins FF0304 Female ORFS Swivel Cap
Tompkins FF0304 female ORFS swivel cap, carbon steel: 8 sizes, 9/16-18 ORFS to 2-12 ORFS.
Key features
- Fitting Configuration: Cap
- Nominal Size Range: 9/16-18 ORFS to 2-12 ORFS
- Fitting Configuration
- Cap
Product description
The Tompkins FF0304 is a carbon steel female ORFS swivel cap from Tompkins Industries' hydraulic adapter range, in 8 sizes from 9/16-18 ORFS to 2-12 ORFS.
Specification
- Configuration: Female ORFS Swivel Cap (cap)
- Material: Carbon steel
- End A: Female ORFS Swivel
- Sizes: 8
Sizes and part numbers
The Sizes & Part Numbers tab lists each Tompkins number with its thread. Tompkins numbers give the style code, then the dash size of each end in the order the ends are named.
Choosing and fitting
Match each end to the port or tube it meets: JIC 37° and SAE O-ring boss share UNF threads at the same dash size but seal differently (37° flare vs an O-ring on the boss), and ORFS seals on an O-ring in the face. Check the thread before installing; never mix sealing types on one joint.
How to order
Quote the Tompkins part number, or the end types and dash sizes. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | Cap |
| Style | Female ORFS Swivel Cap |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 9/16-18 ORFS to 2-12 ORFS |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
Shipping & lead time
Sizes & part numbers
8 sizes| Tompkins part no. | Thread |
|---|---|
| FF0304-C-04 | 9/16-18 ORFS |
| FF0304-C-06 | 11/16-16 ORFS |
| FF0304-C-08 | 13/16-16 ORFS |
| FF0304-C-10 | 1-14 ORFS |
| FF0304-C-12 | 1-3/16-12 ORFS |
| FF0304-C-16 | 1-7/16-12 ORFS |
| FF0304-C-20 | 1-11/16-12 ORFS |
| FF0304-C-24 | 2-12 ORFS |
What sizes is the Tompkins FF0304 made in?▾
Is it carbon steel or stainless?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
The same part, in the designations used across European and Gulf trade catalogues.
- de
- ORFS Verschlusskappe
- fr
- ORFS bouchon femelle
- es
- ORFS tapón hembra
- it
- ORFS cappuccio
