Stainless Steel Wire Rope 6x7+IWS — 0.45–8 mm

Stainless Steel Wire Rope 6x7+IWS, in 21 sizes, 0.45 mm to 8 mm. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Stainless Steel Wire Rope 6x7+IWS
- Size range: 0.45 mm to 8 mm
- Size range
- 0.45 mm to 8 mm
- Material
- Stainless steel
- Finish
- Polished
Product description
Steel wire rope for cranes, winches, slings and guying. Stainless steel, polished.
Sizes and ratings
21 sizes, 0.45 mm to 8 mm. Minimum breaking load 0.142 to 40.6 kN. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Choose on construction, core and grade: more wires per strand bend more easily over a sheave, a steel core resists crushing, and a higher grade carries more for the same diameter. Work from the minimum breaking load and your design factor.
Ordering
Quote the Indus part number from the size table, or send the size and rating you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Stainless Steel Wire Rope 6x7+IWS |
| Sizes | 21 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 0.45 mm to 8 mm |
Performance
| Parameter | Value |
|---|---|
| Minimum breaking load | 0.142 to 40.6 kN |
Construction
| Parameter | Value |
|---|---|
| Material | Stainless steel |
| Finish | Polished |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
21 sizes- Indus part no.IH-LR-WR-SSWR6X7IW-0P45MM
- Size
- 0.45 mm
- Min breaking load (kN)
- 0.142
- Weight (kg/100 m)
- 0.08
- Indus part no.IH-LR-WR-SSWR6X7IW-0P5MM
- Size
- 0.5 mm
- Min breaking load (kN)
- 0.176
- Weight (kg/100 m)
- 0.12
- Indus part no.IH-LR-WR-SSWR6X7IW-0P6MM
- Size
- 0.6 mm
- Min breaking load (kN)
- 0.253
- Weight (kg/100 m)
- 0.15
- Indus part no.IH-LR-WR-SSWR6X7IW-0P7MM
- Size
- 0.7 mm
- Min breaking load (kN)
- 0.345
- Weight (kg/100 m)
- 0.2
- Indus part no.IH-LR-WR-SSWR6X7IW-0P8MM
- Size
- 0.8 mm
- Min breaking load (kN)
- 0.461
- Weight (kg/100 m)
- 0.26
- Indus part no.IH-LR-WR-SSWR6X7IW-0P9MM
- Size
- 0.9 mm
- Min breaking load (kN)
- 0.539
- Weight (kg/100 m)
- 0.32
- Indus part no.IH-LR-WR-SSWR6X7IW-1MM
- Size
- 1 mm
- Min breaking load (kN)
- 0.637
- Weight (kg/100 m)
- 0.4
- Indus part no.IH-LR-WR-SSWR6X7IW-1P2MM
- Size
- 1.2 mm
- Min breaking load (kN)
- 1.2
- Weight (kg/100 m)
- 0.65
Show all 21 sizesShow fewer sizes
- Indus part no.IH-LR-WR-SSWR6X7IW-1P5MM
- Size
- 1.5 mm
- Min breaking load (kN)
- 1.67
- Weight (kg/100 m)
- 0.93
- Indus part no.IH-LR-WR-SSWR6X7IW-1P6MM
- Size
- 1.6 mm
- Min breaking load (kN)
- 2.15
- Weight (kg/100 m)
- 1.2
- Indus part no.IH-LR-WR-SSWR6X7IW-1P8MM
- Size
- 1.8 mm
- Min breaking load (kN)
- —
- Weight (kg/100 m)
- 1.35
- Indus part no.IH-LR-WR-SSWR6X7IW-2MM
- Size
- 2 mm
- Min breaking load (kN)
- 2.94
- Weight (kg/100 m)
- 1.65
- Indus part no.IH-LR-WR-SSWR6X7IW-2P4MM
- Size
- 2.4 mm
- Min breaking load (kN)
- 4.1
- Weight (kg/100 m)
- 2.4
- Indus part no.IH-LR-WR-SSWR6X7IW-3MM
- Size
- 3 mm
- Min breaking load (kN)
- 6.37
- Weight (kg/100 m)
- 3.7
- Indus part no.IH-LR-WR-SSWR6X7IW-3P2MM
- Size
- 3.2 mm
- Min breaking load (kN)
- 7.15
- Weight (kg/100 m)
- 4.2
- Indus part no.IH-LR-WR-SSWR6X7IW-3P5MM
- Size
- 3.5 mm
- Min breaking load (kN)
- 7.64
- Weight (kg/100 m)
- 5.1
- Indus part no.IH-LR-WR-SSWR6X7IW-4MM
- Size
- 4 mm
- Min breaking load (kN)
- 9.51
- Weight (kg/100 m)
- 6.5
- Indus part no.IH-LR-WR-SSWR6X7IW-4P5MM
- Size
- 4.5 mm
- Min breaking load (kN)
- 12.1
- Weight (kg/100 m)
- 8.3
- Indus part no.IH-LR-WR-SSWR6X7IW-5MM
- Size
- 5 mm
- Min breaking load (kN)
- 14.7
- Weight (kg/100 m)
- 10.5
- Indus part no.IH-LR-WR-SSWR6X7IW-6MM
- Size
- 6 mm
- Min breaking load (kN)
- 18.6
- Weight (kg/100 m)
- 15.1
- Indus part no.IH-LR-WR-SSWR6X7IW-8MM
- Size
- 8 mm
- Min breaking load (kN)
- 40.6
- Weight (kg/100 m)
- 26.6
Size — Nominal size as the manufacturer states it. Min breaking load — Minimum breaking load. A test figure — never lift to it. Weight — Weight per 100 metres, as published. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
This range is published with a breaking load only, not a working load limit. Tell us the duty before using it to lift, and we will confirm a rating or recommend a rated part.
What is the Stainless Steel Wire Rope 6x7+IWS and where is it used?▾
How do I read Stainless Steel Wire Rope 6x7+IWS part numbers such as IH-LR-WR-SSWR6X7IW-0P45MM?▾
Which sizes does the Stainless Steel Wire Rope 6x7+IWS come in?▾
How should I pick the size of Stainless Steel Wire Rope 6x7+IWS for my job?▾
What load rating does the Stainless Steel Wire Rope 6x7+IWS carry?▾
What is the Stainless Steel Wire Rope 6x7+IWS made from and how is it finished?▾
Does the Stainless Steel Wire Rope 6x7+IWS come with a test certificate?▾
Which parts connect to the Stainless Steel Wire Rope 6x7+IWS?▾
How should the Stainless Steel Wire Rope 6x7+IWS be fitted and inspected?▾
How does the Stainless Steel Wire Rope 6x7+IWS compare with the 6x7 and 6x9 Steel Wire Rope?▾
Can you export the Stainless Steel Wire Rope 6x7+IWS from Dubai?▾
Do you hold the Stainless Steel Wire Rope 6x7+IWS for delivery from Dubai?▾
