Parker 6100 Series Thread-to-Connect Hydraulic Couplings
Parker 6100 Series thread-to-connect steel couplings, connectable under pressure, including low-spill and high-flow sizes, with NPTF ends.
Key features
- Fitting Configuration: 6100 Series Thread-to-Connect Hydraulic Couplings
- Nominal Size Range: 17 part numbers
- Fitting Configuration
- 6100 Series Thread-to-Connect Hydraulic Couplings
Product description
Parker 6100 Series thread-to-connect steel couplings, connectable under pressure, including low-spill and high-flow sizes, with NPTF ends.
Specification
- Parts: nipple (male half) (2)
- Material: Steel
- Rated pressure stated by the maker: 2,750 to 3,000 psi depending on size
- Rated flow: 12 to 76 GPM depending on size
- Part numbers: 17
Sizes and part numbers
The Sizes & Part Numbers tab lists every Parker part number with its connection. Ratings vary by size and connection — check the row for the part you order.
Matching halves
Quick couplings only seal and flow at their rating when both halves come from the same interchange profile. Quote the part number of the mating half too, or tell us what it must connect to, and we will confirm the match before supply.
How to order
Quote the Parker part number. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | 6100 Series Thread-to-Connect Hydraulic Couplings |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 17 part numbers |
Construction
| Parameter | Value |
|---|---|
| Material | Steel |
Performance
| Parameter | Value |
|---|---|
| Rated Pressure | 2,750–3,000 psi |
Shipping & lead time
Sizes & part numbers
17 sizes| Parker Hannifin part no. | Description | Type | Body size | Port | Rated pressure (psi) | Rated flow (GPM) |
|---|---|---|---|---|---|---|
| 6105-12 | Steel Male NPTF Coupling 3/4" NPTF | — | — | 3/4 inch NPTF | — | — |
| 6105-16K | Steel Male NPTF Coupling – High Flow | — | — | — | — | — |
| 6105-20 | Thread-to-Connect Low Spill Coupling | — | — | — | — | — |
| 6105-20K | Steel Low Spill Coupling NPTF 1 1/4 | — | — | — | — | — |
| 6105-24 | 6100 Series Male NPTF 1 1/2 NPTF Fitting | — | — | 1 1/2 inch NPTF | — | — |
| 6115-12 | 6100 Series Female NPTF Coupling | — | — | 3/4 inch NPTF | — | — |
| 6115-16 | 6100 Series 1 NPTF High Flow Coupling | — | — | 1 inch NPTF | — | — |
| 6115-24 | 6100 Series Female NPTF – 1 1/2 NPTF | — | — | 1 1/2 NPTF | — | — |
| 6125-08 | 6100 Series Female NPTF 1/2 NPTF Connection | — | — | 1/2 NPTF | — | — |
| 6125-12 | 6100 Series Female NPTF Hydraulic Coupling | — | — | — | — | — |
| 6125-16 | 6100 Series Female NPTF Coupling High Flow | — | — | 1 inch NPTF | — | — |
| 6125-16K | 6100 Series Female NPTF Coupling | — | — | — | — | — |
| 6125-20 | 6100 Series Female NPTF Coupling | — | — | — | — | — |
| 6125-20K | 6100 Series Female NPTF – 1 1/4 NPTF | — | — | 1 1/4 NPTF | — | — |
| 6125-24 | 6100 Series Female NPTF Coupling 1 1/4 NPT | — | — | 1 1/4 inch NPTF | — | — |
| 6115-08 | 3/4", Female Nipple, 1/2-14 NPTF, 12GPM, 3,000 PSI, Connect Under Pressure | Nipple (male half) | 3/4" | 1/2-14 NPTF | 3,000 | 12 |
| 6115-20 | 1 1/4", Female Nipple, 1 1/4-11 1/2 NPTF, 76 GPM, 2,750 PSI, Connect Under Pressure, 6100 | Nipple (male half) | 1 1/4" | 1 1/4-11 1/2 NPTF | 2,750 | 76 |
Description — What this part number is, as the manufacturer lists it. Type — Which part of the coupling this is: coupler (female half), nipple (male half), complete set, dust cap or adapter. Body size — Nominal body size of the coupling, which sets which halves mate. Rated pressure — Rated working pressure, as the manufacturer publishes it. A circuit is limited by its lowest-rated component. Rated flow — Rated flow in US gallons per minute, as the manufacturer publishes it. A circuit is limited by its lowest-rated component. Ask us for the dimension drawing if you need it stamped.
Pressure, flow, speed, torque and load figures are the manufacturer’s published ratings for that part number. A circuit is limited by its lowest-rated component, so check them against the hose, fittings and valves it connects to.
Which part numbers are in this Parker range?▾
What pressure is it rated for?▾
Will it connect to my existing coupler?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
