Parker 9200 Series Lever-Operated Coupling & Dust Cap
Parker 9200 Series lever-operated quick-disconnect coupling, which the listing says operates under pressure, with its dust cap.
Key features
- Fitting Configuration: 9200 Series Lever-Operated Coupling & Dust Cap
- Nominal Size Range: 2 part numbers
- Fitting Configuration
- 9200 Series Lever-Operated Coupling & Dust Cap
Product description
Parker 9200 Series lever-operated quick-disconnect coupling, which the listing says operates under pressure, with its dust cap.
Specification
- Parts: dust cap (1)
- Material: Rubber, Steel
- Part numbers: 2
Sizes and part numbers
The Sizes & Part Numbers tab lists every Parker part number with its connection. Ratings vary by size and connection — check the row for the part you order.
Matching halves
Quick couplings only seal and flow at their rating when both halves come from the same interchange profile. Quote the part number of the mating half too, or tell us what it must connect to, and we will confirm the match before supply.
How to order
Quote the Parker part number. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | 9200 Series Lever-Operated Coupling & Dust Cap |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 2 part numbers |
Construction
| Parameter | Value |
|---|---|
| Material | Rubber |
Shipping & lead time
Sizes & part numbers
2 sizes| Parker Hannifin part no. | Description | Type |
|---|---|---|
| 9500-4 | Quick Disconnect Couplings 9200 Series | — |
| 9507-4-1 | 9200 Series Quick Disconnect Dust Cap | Dust cap |
Description — What this part number is, as the manufacturer lists it. Type — Which part of the coupling this is: coupler (female half), nipple (male half), complete set, dust cap or adapter. Ask us for the dimension drawing if you need it stamped.
Which part numbers are in this Parker range?▾
Will it connect to my existing coupler?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
The same part, in the designations used across European and Gulf trade catalogues.
- de
- Verschlusskappe
- fr
- bouchon femelle
- es
- tapón hembra
- it
- cappuccio
