Flat Mount Block — 1,000–3,000 lbs WLL

Flat Mount Block, in 3 sizes, 2″ to 4″, WLL 1,000 to 3,000 lbs. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Flat Mount Block
- Size range: 2″ to 4″
- Working load limit: 1,000 to 3,000 lbs
- Size range
- 2″ to 4″
- Working load limit
- 1,000 to 3,000 lbs
- Material
- Carbon steel
- Finish
- Galvanized
Product description
Snatch blocks and pulley blocks change the direction of a rope or multiply a line pull. Carbon steel, galvanized.
Sizes and ratings
3 sizes, 2″ to 4″. Working load limit 1,000 to 3,000 lbs. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Rate the block for the load it actually sees: with the rope turned through 180° it carries about twice the line pull. Match the sheave to the rope diameter.
Ordering
Quote the Indus part number from the size table, or send the size and rating you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Flat Mount Block |
| Sizes | 3 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 2″ to 4″ |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 1,000 to 3,000 lbs |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
| Finish | Galvanized |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
3 sizes- Indus part no.IH-LR-BP-FMB-200
- Size
- 2″
- Rope size
- 7/32″
- WLL (lbs)
- 1,000
- Weight (kg)
- 0.31
- Indus part no.IH-LR-BP-FMB-300
- Size
- 3″
- Rope size
- 5/16″
- WLL (lbs)
- 2,000
- Weight (kg)
- 0.86
- Indus part no.IH-LR-BP-FMB-400
- Size
- 4″
- Rope size
- 3/8″
- WLL (lbs)
- 3,000
- Weight (kg)
- 2.13
Size — Nominal size as the manufacturer states it. Rope size — Rope diameter the sheave is made for. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What is the Flat Mount Block used for?▾
What sizes does the Flat Mount Block come in?▾
How do I size the Flat Mount Block for a job?▾
What WLL does the Flat Mount Block carry?▾
How do I order a specific size of the Flat Mount Block?▾
When should I choose the Flat Mount Block instead of the Flat Mount Pulley Block?▾
What material and finish does the Flat Mount Block have?▾
What standard and certificate come with the Flat Mount Block?▾
What can the Flat Mount Block be connected to?▾
How should the Flat Mount Block be inspected and used?▾
What are the typical applications of the Flat Mount Block?▾
Can I buy the Flat Mount Block from Indus ex-stock?▾
