Cutting Ring, DIN 3861 Heavy Series
Cutting Ring, DIN 3861 Heavy Series — 10 sizes, 6 mm to 38 mm tube O.D..
Key features
- Fitting Configuration: straight
- Nominal Size Range: 6 mm to 38 mm tube O.D.
- Fitting Configuration
- straight
- Nominal Size Range
- 6 mm to 38 mm tube O.D.
Product description
The Cutting Ring, DIN 3861 Heavy Series is part of the Indus hydraulic connection range.
The heavy-series ring, for the thicker-walled tube the S range uses. Light and heavy rings are not interchangeable even where the tube diameter matches.
Construction
- Configuration: straight
- Material: carbon steel, zinc-plated and Cr3+ passivated (316 stainless on request)
Sizes
10 sizes, 6 mm to 38 mm tube O.D.. The full size and dimension table is on this page.
How to order
Quote the Indus part number for the size you need. Tell us the hose grade and bore and we will include the matching crimp ferrule — the ferrule follows the hose, not the fitting. Indus crimps and pressure-tests assemblies before dispatch.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | straight |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 6 mm to 38 mm tube O.D. |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel (316 stainless on request) |
| Surface Treatment | Zinc-plated, Cr3+ passivated, RoHS-compliant |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | DIN 3861, heavy series |
Shipping & lead time
Sizes & part numbers
10 sizes| Indus part no. | Tube O.D. (mm) |
|---|---|
| IH-DF-RING-HS-06 | 6 |
| IH-DF-RING-HS-08 | 8 |
| IH-DF-RING-HS-10 | 10 |
| IH-DF-RING-HS-12 | 12 |
| IH-DF-RING-HS-14 | 14 |
| IH-DF-RING-HS-16 | 16 |
| IH-DF-RING-HS-20 | 20 |
| IH-DF-RING-HS-25 | 25 |
| IH-DF-RING-HS-30 | 30 |
| IH-DF-RING-HS-38 | 38 |
Tube O.D. — Outside diameter of the tube the port is cut for. Ask us for the dimension drawing if you need it stamped.
Every size is available in 316 stainless steel on request — add “-SS” to the part number when you enquire.
What sizes are available?▾
What is the maximum working pressure?▾
Which ferrule pairs with this fitting?▾
Is stainless steel available?▾
Can Indus crimp the assembly?▾
