90° Metric Female 24° Cone (Heavy Series) Hose Fitting

The 90° Metric Female 24° Cone (Heavy Series) Hose Fitting is a 90 elbow hydraulic hose fitting in the DIN family — female-swivel thread with 24° cone, metal-to-metal (no O-ring) sealing form. Compliant with DIN 2353, ISO 8434-1, ISO 12151-2.

Construction

• Configuration: 90-elbow
• Thread form: Metric (24° cone — DIN 2353 / ISO 8434-1, heavy series)
• Sealing form: 24° cone, metal-to-metal (no O-ring)
• Gender: female-swivel
• Series: heavy-series
• Material: Carbon steel (stainless steel available on request)
• Surface treatment: Zinc-plated, Cr3+ passivated, RoHS-compliant
• Notes: Metal-to-metal seat — for plain DIN 24° ports. Heavy series (S): higher pressure rating than light series (L), and not interchangeable with L-series ports.

Performance

Pressure rating matches the matching ferrule and host hose grade — see Indus Crimp Ferrules for compatibility tables. Tested to manufacturer-recommended impulse cycles when crimped to the correct ferrule diameter. Operating temperature -40°C to +120°C; refer to fluid compatibility chart for aggressive media.

Metal-to-metal or O-ring?

This is the metal-to-metal 24° cone — the seal is made by the cone seat itself, with no elastomer in the joint. It mates to a plain DIN 2353 24° port. If your port has an O-ring groove in the cone, you need the soft-seal version instead (see the Metric Female 24° O-ring Cone fittings in this category). The two look nearly identical and will not seal against each other's ports.

Applicable Standards

• DIN 2353
• ISO 8434-1
• ISO 12151-2

How to order

Specify (a) the host hose grade and bore size, (b) the matching crimp ferrule (see the Crimp Ferrules category), and (c) the thread size you need. Indus crimps and pressure-tests the assembly before dispatch.

Companion products

Pair with Indus crimp ferrules from the matching hose grade. For other thread families see the Metric, BSP, JIC 37°, DIN, and Japanese sub-categories under Hose Fittings.
