45° Metric Female Multiseal Hose Fitting
45° Metric Female Multiseal — 60° cone seat, metal-to-metal (no O-ring), 26 sizes, -03 to -24.
Key features
- Fitting Configuration: 45-elbow
- Thread Form: M10×1 to M52×2
- Sealing Form: 60° cone seat, metal-to-metal (no O-ring)
- Nominal Size Range: -03 to -24
- Fitting Configuration
- 45-elbow
- Thread Form
- M10×1 to M52×2
- Sealing Form
- 60° cone seat, metal-to-metal (no O-ring)
- Nominal Size Range
- -03 to -24
Product description
The 45° Metric Female Multiseal Hose Fitting is a hydraulic hose fitting with 60° cone seat, metal-to-metal (no O-ring).
The supplier calls this series "multiseal" and does not define the term. Measured against its own catalogue it is unambiguous: at every shared thread and bore the seat depth sits within about a millimetre of the 60° cone and four to five millimetres away from both the flat seat and the 74° cone. What it does not carry is an O-ring — the 24° multiseal sits beside its O-ring twin in the same book with an identical thread, tube diameter and hex, and no O-ring column at all.
Construction
- Configuration: 45 elbow
- Thread: M10×1 to M52×2
- Sealing form: 60° cone seat, metal-to-metal (no O-ring)
- Gender: female-swivel
- Material: carbon steel, zinc-plated and Cr3+ passivated (316 stainless on request)
Sizes
26 sizes, -03 to -24, threads M10×1 to M52×2. The full size and dimension table is on this page.
How to order
Quote the Indus part number for the size you need. Tell us the hose grade and bore and we will include the matching crimp ferrule — the ferrule follows the hose, not the fitting. Indus crimps and pressure-tests assemblies before dispatch.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | 45-elbow |
| Thread Form | M10×1 to M52×2 |
| Sealing Form | 60° cone seat, metal-to-metal (no O-ring) |
| Thread Gender | female-swivel |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | -03 to -24 |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel (316 stainless on request) |
| Surface Treatment | Zinc-plated, Cr3+ passivated, RoHS-compliant |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | Metric thread to ISO 261 (coarse and fine pitch) |
