Snatch Block with Eye — 1.5–8 t WLL

Snatch Block with Eye, in 5 sizes, 3″ to 8″, WLL 1.5 to 8 t. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Snatch Block with Eye
- Size range: 3″ to 8″
- Working load limit: 1.5 to 8 t
- Size range
- 3″ to 8″
- Working load limit
- 1.5 to 8 t
- Finish
- Painted red
Product description
Snatch blocks and pulley blocks change the direction of a rope or multiply a line pull. Painted red.
Sizes and ratings
5 sizes, 3″ to 8″. Working load limit 1.5 to 8 t. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Rate the block for the load it actually sees: with the rope turned through 180° it carries about twice the line pull. Match the sheave to the rope diameter.
Ordering
Quote the Indus part number from the size table, or send the size and working load you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Snatch Block with Eye |
| Sizes | 5 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 3″ to 8″ |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 1.5 to 8 t |
Construction
| Parameter | Value |
|---|---|
| Finish | Painted red |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
5 sizes- Indus part no.IH-LR-BP-RBE-300
- Size
- 3″
- Rope size
- 4--6 mm
- WLL (t)
- 1.5
- Weight (kg)
- 1.65
- Indus part no.IH-LR-BP-RBE-400
- Size
- 4″
- Rope size
- 6--9 mm
- WLL (t)
- 3
- Weight (kg)
- 2.9
- Indus part no.IH-LR-BP-RBE-500
- Size
- 5″
- Rope size
- 8--12 mm
- WLL (t)
- 4.5
- Weight (kg)
- 5.4
- Indus part no.IH-LR-BP-RBE-600
- Size
- 6″
- Rope size
- 10--14 mm
- WLL (t)
- 6
- Weight (kg)
- 7.95
- Indus part no.IH-LR-BP-RBE-800
- Size
- 8″
- Rope size
- 14--18 mm
- WLL (t)
- 8
- Weight (kg)
- 18.05
Size — Nominal size as the manufacturer states it. Rope size — Rope diameter the sheave is made for. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What is the Snatch Block with Eye and what is it used for?▾
Which sizes of Snatch Block with Eye are available?▾
How do I choose the right size of Snatch Block with Eye?▾
What is the working load limit of the Snatch Block with Eye?▾
How do I order a specific size of the Snatch Block with Eye?▾
How does the Snatch Block with Eye compare with the Eye Swivel Snatch Block?▾
What is the Snatch Block with Eye made of?▾
Which standard does the Snatch Block with Eye meet?▾
What can the Snatch Block with Eye be connected to?▾
How should the Snatch Block with Eye be inspected and used?▾
What are the typical applications of the Snatch Block with Eye?▾
Does Indus stock the Snatch Block with Eye in Dubai?▾
