SAE O-Ring Boss × JIC Female 74° Seat — JIC adapter, straight body, 18 orderable sizes on this page. RFQ-only; standard Indus zinc-plated carbon-steel construction.
Key features
- Body Configuration: straight
- Port A Thread: UN/UNF 7/16-20 to 1.5/8-12
- Port A Sealing: SAE O-ring boss
- Nominal Size Range: -04 to -20
- Max Working Pressure: up to 315 bar (4,569 psi), manufacturer stated
- Body Configuration
- straight
- Port A Thread
- UN/UNF 7/16-20 to 1.5/8-12
- Port A Sealing
- SAE O-ring boss
- Nominal Size Range
- -04 to -20
- Max Working Pressure
- up to 315 bar (4,569 psi), manufacturer stated
Product description
The SAE O-Ring Boss × JIC Female 74° Seat is a straight hydraulic adapter in the Indus JIC range. Every size the manufacturer publishes is listed in the Sizes & Part Numbers tab, with the thread on each end, the dimensions, the weight and the working pressure.
Construction
- Body configuration: straight
- Port A: SAE O-Ring Boss L-Series
- Port B: JIC Female 74° Seat
- Material: carbon steel (stainless steel available on request)
- Surface treatment: zinc-plated, Cr3+ passivated, RoHS-compliant
Threads
- Port A: UN/UNF 7/16-20 to 1.5/8-12
- Port B: UN/UNF 7/16-20 to 1.5/8-12
Sealing
SAE O-ring boss and JIC 37° cone (74° included). Match the seat as well as the thread — a thread that engages against the wrong seat will weep under pressure, and several of these families share a thread while sealing differently.
Performance
The manufacturer states 160 to 315 bar depending on size, printed against every size in the table. That is the rating of the adapter; an assembly is limited by whichever component is rated lowest — the hose, the tube or the port.
Applicable standards
SAE J1926, ISO 11926, SAE J514, ISO 8434-2.
How to order
Quote the Indus part number from the size table. If you have only the ports, send us the thread on each end and whether you need carbon steel or stainless, and Indus engineering will confirm the part number against your equipment.
Companion products
These are tube and port adapters, not hose ends. For hose assemblies pair them with Indus crimp ferrules and the matching hose-end fitting; for tube runs, with Indus cutting rings and end nuts.
Identification
| Parameter | Value |
|---|---|
| Body Configuration | straight |
Port A
| Parameter | Value |
|---|---|
| Port A Thread | UN/UNF 7/16-20 to 1.5/8-12 |
| Port A Sealing | SAE O-ring boss |
Port B
| Parameter | Value |
|---|---|
| Port B Thread | UN/UNF 7/16-20 to 1.5/8-12 |
| Port B Sealing | JIC 37° cone (74° included) |
| Port B Gender | female |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | -04 to -20 |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | up to 315 bar (4,569 psi), manufacturer stated |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel (stainless on request) |
| Surface Treatment | Zinc-plated, Cr3+ passivated, RoHS-compliant |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | SAE J1926, ISO 11926, SAE J514, ISO 8434-2 |
