High Temperature Air Hose 40 Bar
Robust heavy duty high pressure air hose for quarry, mining and construction industries
Key features
- Application Family: air-water
- Manufacturer Part Code: A116EU100
- Inner Diameter Range: 51 mm to 102 mm
- Max Working Pressure: 40 bar
- Operating Temperature: From -30°C to +100°C
- Application Family
- air-water
- Manufacturer Part Code
- A116EU100
- Inner Diameter Range
- 51 mm to 102 mm
- Max Working Pressure
- 40 bar
- Operating Temperature
- From -30°C to +100°C
Product description
The High Temperature Air Hose 40 Bar (part code A116EU100) is a Air / Water Hose from the Indus Hydraulics industrial hose range.
Application
Robust heavy duty high pressure air hose for quarry, mining and construction industries
Construction
- Cover: Yellow pin pricked, mandrel wrap, ozone, oil mist and weather resistant EPDM
- Lining / Tube: Black SBR oil mist resistant
- Reinforcement: High tensile strength steel wire plies
- Branding (printed on hose): INDUS LOGO A116EU100 AIR 40 BAR S:F 3:1
Performance
- Inner-diameter range: 51 mm to 102 mm
- Max working pressure: 40 bar
- Min burst pressure: 120 bar
- Min bend radius: 510-1020 mm
- Weight: 1.97-5.65 kg/m
- Operating temperature: From -30°C to +100°C
- Safety factor: 3:1
Family context
Air & water hoses for compressed air, pneumatic tools, water transfer, and general industrial utility — typically 20 bar working pressure with EPDM/SBR rubber tube and textile reinforcement. BS 5118/2, ISO 2398.
How to order
Specify (a) the inner diameter from the size range, (b) the assembly length, (c) end-fitting requirements, and (d) any special requirements such as Lloyd's certification or third-party witness testing. Indus engineering will confirm the assembly drawing on the RFQ.
Companion products
Pair with matching couplings and accessories (Cam & Groove, Boss steam couplings, hose clamps, Holedall permanently-attached fittings, hose tags, and Spiral Hose Guard / Fire Jacket protective sleeves) — full range available on quote.
Identification
| Parameter | Value |
|---|---|
| Application Family | air-water |
| Manufacturer Part Code | A116EU100 |
| Hose Branding (Printed) | INDUS LOGO A116EU100 AIR 40 BAR S:F 3:1 |
Dimensions
| Parameter | Value |
|---|---|
| Inner Diameter Range | 51 mm to 102 mm |
| Min Bend Radius | 510-1020 mm |
| Weight | 1.97-5.65 kg/m |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | 40 bar |
| Min Burst Pressure | 120 bar |
| Operating Temperature | From -30°C to +100°C |
| Safety Factor | 3:1 |
Construction
| Parameter | Value |
|---|---|
| Cover Material | Yellow pin pricked, mandrel wrap, ozone, oil mist and weather resistant EPDM |
| Lining / Tube Material | Black SBR oil mist resistant |
| Reinforcement | High tensile strength steel wire plies |
Shipping & lead time
Sizes & part numbers
3 sizes| Indus part no. | Hose bore | O.D. (mm) | Min burst (bar) | Min bend radius (mm) | Weight (kg/m) | Working pressure (bar) |
|---|---|---|---|---|---|---|
| IH-IH-A116EU100-051 | 2" · DN51 | 65 | 120 | 510 | 1.97 | 40 |
| IH-IH-A116EU100-076 | 3" · DN76 | 95 | 120 | 760 | 4.33 | 40 |
| IH-IH-A116EU100-102 | 4" · DN102 | 121 | 120 | 1020 | 5.65 | 40 |
O.D. — Outside diameter of the hose, which is what a clamp or a ferrule has to close on. Min burst — Minimum burst pressure. A test figure, never a working limit — never select on it. Min bend radius — Tightest centreline radius the hose may be bent to at full working pressure. Weight — Weight of the hose per metre, as published.
Working pressure is the published rating for the hose itself. A made-up assembly is limited by its lowest-rated part, so check it against the coupling, the clamp or ferrule, and the temperature you are running at.
Cut lengths and made-up assemblies are prepared in Dubai. Tell us the bore, the length and the ends you need.
What is this hose used for?▾
What sizes are available?▾
What is the maximum working pressure?▾
What is the operating temperature range?▾
What is the construction (cover / lining / reinforcement)?▾
What is the printed branding on the hose?▾
Lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
