Grade 100 Shortening Clevis Link
Grade 100 Shortening Clevis Link, in 6 sizes, 5.5 mm (7/32″) to 16 mm (5/8″), WLL 2,700 to 22,600 lbs. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Shortening clevis link
- Pattern / standard: Grade 100
- Size range: 5.5 mm (7/32″) to 16 mm (5/8″)
- Working load limit: 2,700 to 22,600 lbs
- Size range
- 5.5 mm (7/32″) to 16 mm (5/8″)
- Working load limit
- 2,700 to 22,600 lbs
- Material
- Alloy steel, quenched and tempered
- Finish
- Powder coated
Product description
Grade 100 in-line chain shortener: an eye at the top and a clevis pocket that takes a link of the chain, so a sling leg can be set to length without a separate grab hook.
Sizes and ratings
6 sizes, 5.5 mm (7/32″) to 16 mm (5/8″). Working load limit 2,700 to 22,600 lbs. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in. The lettered dimensions refer to the dimension drawing in the gallery.
Choosing a size
Fitted in the line of the leg and used with chain of the size it is marked for. Each row is the link for one Grade 100 chain size and carries that chain's working load limit.
Ordering
Quote the Indus part number from the size table, or send the size and working load you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Shortening clevis link |
| Pattern / standard | Grade 100 |
| Sizes | 6 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 5.5 mm (7/32″) to 16 mm (5/8″) |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 2,700 to 22,600 lbs |
Construction
| Parameter | Value |
|---|---|
| Material | Alloy steel, quenched and tempered |
| Finish | Powder coated |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
6 sizes| Indus part no. | Size | WLL (lbs) | a (mm) | b (mm) | d1 (mm) | d2 (mm) | e (mm) | g (mm) | Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|
| IH-LR-G10-SHCL-5P5MM | 5.5 mm (7/32″) | 2,700 | 28.4 | 37.1 | 18 | 8.9 | 84.1 | 7.9 | 0.66 |
| IH-LR-G10-SHCL-7MM | 7 mm (9/32″) | 4,300 | 39.1 | 54.1 | 23.9 | 11.9 | 121.9 | 10.4 | 1.37 |
| IH-LR-G10-SHCL-8MM | 8 mm (5/16″) | 5,700 | 39.1 | 54.1 | 23.9 | 11.9 | 121.9 | 10.4 | 2.76 |
| IH-LR-G10-SHCL-10MM | 10 mm (3/8″) | 8,800 | 50 | 69.6 | 31 | 14 | 159 | 13 | 2.76 |
| IH-LR-G10-SHCL-13MM | 13 mm (1/2″) | 15,000 | 64 | 91.9 | 37.1 | 18 | 202.9 | 15 | 5.95 |
| IH-LR-G10-SHCL-16MM | 16 mm (5/8″) | 22,600 | 80 | 102.1 | 48 | 23.9 | 233.9 | 20.1 | 10.58 |
Size — Nominal size as the manufacturer states it. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. a — Dimension a on the manufacturer dimension drawing. b — Dimension b on the manufacturer dimension drawing. d1 — Dimension d1 on the manufacturer dimension drawing. d2 — Dimension d2 on the manufacturer dimension drawing. e — Dimension e on the manufacturer dimension drawing. g — Dimension g on the manufacturer dimension drawing. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What sizes does the Grade 100 shortening clevis link come in?▾
What is the working load limit?▾
Do the parts come with a test certificate?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
From the blog
Written about this part
Engineers viewing this also looked at
Grade 100 Clevis Self Locking Safety Hook
Grade 100 Eye Self Locking Safety Hook
Grade 100 Swivel Self Locking Hook
Grade 100 Swivel Self Locking Hook with Grip Latch — LBK Type
Grade 100 Twist Lock Cradle Grab Hook
