Dixon Wing-Style Hydraulic Couplers
Wing-style (thread-to-connect) hydraulic couplers with female NPT ends, listed by body size and port thread.
Key features
- Fitting Configuration: Wing-Style Hydraulic Couplers
- Nominal Size Range: 16 part numbers
- Fitting Configuration
- Wing-Style Hydraulic Couplers
Product description
Wing-style (thread-to-connect) hydraulic couplers with female NPT ends, listed by body size and port thread.
Specification
- Parts: coupler (female half) (3), nipple (male half) (3)
- Rated pressure stated by the maker: 2,500 to 4,000 psi depending on size
- Rated flow: 28 to 76 GPM depending on size
- Part numbers: 16
Sizes and part numbers
The Sizes & Part Numbers tab lists every Dixon part number with its connection. Ratings vary by size and connection — check the row for the part you order.
Matching halves
Quick couplings only seal and flow at their rating when both halves come from the same interchange profile. Quote the part number of the mating half too, or tell us what it must connect to, and we will confirm the match before supply.
How to order
Quote the Dixon part number. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | Wing-Style Hydraulic Couplers |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | 16 part numbers |
Performance
| Parameter | Value |
|---|---|
| Rated Pressure | 2,500–4,000 psi |
Shipping & lead time
Sizes & part numbers
16 sizes| Dixon Valve & Coupling part no. | Description | Type | Body size | Flange size | Rated pressure (psi) | Rated flow (GPM) |
|---|---|---|---|---|---|---|
| 10WF10-B | 10WF10B | 1 1/4" Wingstyle Coupler x 1 1/4" FNPT | — | 1 1/4" | 1 1/4" | 3,000 | — |
| 12WF12-B | 1 1/2" Wingstyle Coupler x 1 1/2" FNPT | — | 1 1/2" | 1 1/2" | 2,500 | — |
| 6WF4-B | 3/4" Wingstyle Coupler x 1/2" FNPT | — | 3/4" | 1/2" | 3,000 | — |
| 6WF6-B | 3/4" Wingstyle Coupler x 3/4" FNPT | — | 3/4" | 3/4" | 3,000 | — |
| 8WF8-B | 1" Wingstyle Coupler x 1" FNPT | — | 1" | 1" | 4,000 | — |
| W10F10-B | 1 1/4" Wingstyle Plug x 1 1/4" FNPT | — | 1 1/4" | 1 1/4" | 3,000 | — |
| W12F12-B | 1 1/2" Wingstyle Plug x 1 1/2" FNPT | — | 1 1/2" | 1 1/2" | 2,500 | — |
| W6F4-B | 3/4" Wingstyle Plug x 1/2" FNPT | — | 3/4" | 1/2" | 3,000 | — |
| W6F6-B | 3/4" Wingstyle Plug x 3/4" FNPT | — | 3/4" | 3/4" | 3,000 | — |
| W8F8-B | 1" Wingstyle Plug x 1" FNPT | — | 1" | 1" | 4,000 | — |
| S515W-10 | 1-1/4" Wing Coupler, Female Body Half | Coupler (female half) | 1-1/4" | — | 2,500 | 76 |
| S515W-6 | 3/4" Wing Coupler, Female Body Half | Coupler (female half) | 3/4" | — | 3,000 | 28 |
| S515W-8 | 1" Wing Coupler, Female Body Half | Coupler (female half) | 1" | — | 3,000 | 50 |
| S511-10 | 1-1/4" Wing Coupler, Male Tip Half | Nipple (male half) | 1-1/4" | — | 2,500 | 76 |
| S511-6 | 3/4" Wing Coupler, Male Tip Half | Nipple (male half) | 3/4" | — | 3,000 | 28 |
| S511-8 | 1" Wing Coupler, Male Tip Half | Nipple (male half) | 1" | — | 3,000 | 50 |
Description — What this part number is, as the manufacturer lists it. Type — Which part of the coupling this is: coupler (female half), nipple (male half), complete set, dust cap or adapter. Body size — Nominal body size of the coupling, which sets which halves mate. Rated pressure — Rated working pressure, as the manufacturer publishes it. A circuit is limited by its lowest-rated component. Rated flow — Rated flow in US gallons per minute, as the manufacturer publishes it. A circuit is limited by its lowest-rated component. Ask us for the dimension drawing if you need it stamped.
Pressure, flow, speed, torque and load figures are the manufacturer’s published ratings for that part number. A circuit is limited by its lowest-rated component, so check them against the hose, fittings and valves it connects to.
Which part numbers are in this Dixon range?▾
What pressure is it rated for?▾
Will it connect to my existing coupler?▾
What is the lead time?▾
