Tompkins 6801-S Male JIC 37° × Male O-Ring Boss Swivel Adjustable 90° Elbow
Tompkins 6801-S male JIC 37° × male o-ring boss swivel adjustable 90° elbow, swivel, carbon steel: 3 sizes, 9/16-18 JIC upward.
Key features
- Fitting Configuration: 90° elbow, swivel
- Fitting Configuration
- 90° elbow, swivel
Product description
The Tompkins 6801-S is the swivel version of the 6801, with a swivel nut on one end so it can be aligned without turning the body: male JIC 37° × male o-ring boss swivel adjustable 90° elbow, carbon steel, in 3 sizes.
Specification
- End A: Male JIC 37°
- End B: Male O-Ring Boss Swivel
- Form: swivel, 90° elbow
- Material: carbon steel
- Sizes: 3
When to use it
Use the swivel version where the fitting has to be lined up after the other end is tight, so the line does not have to be twisted into place.
How to order
Quote the Tompkins part number, or the end types and dash sizes. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Fitting Configuration | 90° elbow, swivel |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel |
Shipping & lead time
Sizes & part numbers
3 sizes| Tompkins part no. | End 1 | End 2 |
|---|---|---|
| 6801-S-06-06 | 9/16-18 JIC | 9/16-18 ORB |
| 6801-S-08-08 | 3/4-16 JIC | 3/4-16 ORB |
| 6801-S-10-10 | 7/8-14 JIC | 7/8-14 ORB |
End 1 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. End 2 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. Ask us for the dimension drawing if you need it stamped.
How is the 6801-S different from the standard 6801?▾
What is the lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
