Steel Metric Dual-Purpose Male (Port or 24° Tube) × NPTF Female Adapter, L Series
Steel Metric Dual-Purpose Male (Port or 24° Tube) × NPTF Female Adapter, L Series, forged carbon steel, trivalent zinc plated. 11 part numbers, M12×1.5 to M26×1.5; the size table gives the size on each end and the tube O.D. for every Indus part number.
Key features
- Body Configuration: straight adapter
- Port A Thread: metric 24° cone / port (dual purpose), M12×1.5 to M26×1.5
- Port A Sealing: dual-purpose metric end: takes a DIN 2353 24° tube nut and cutting ring, or screws into a metric port
- Nominal Size Range: M12×1.5 to M26×1.5
- Body Configuration
- straight adapter
- Port A Thread
- metric 24° cone / port (dual purpose), M12×1.5 to M26×1.5
- Port A Sealing
- dual-purpose metric end: takes a DIN 2353 24° tube nut and cutting ring, or screws into a metric port
Product description
The Steel Metric Dual-Purpose Male (Port or 24° Tube) × NPTF Female Adapter, L Series is a straight adapter, in forged carbon steel, trivalent zinc plated. Its ends are metric 24° cone / port (dual purpose) male and NPTF (Dryseal) female. Metric adapters join metric ports and 24° cone tube ends to JIC, BSP and NPT lines.
Construction
- Body: straight adapter
- End 1: metric 24° cone / port (dual purpose) male
- End 2: NPTF (Dryseal) female
- Material: forged carbon steel, trivalent zinc plated
Ends and sealing
- metric 24° cone / port (dual purpose): dual-purpose metric end: takes a DIN 2353 24° tube nut and cutting ring, or screws into a metric port; DIN 2353 / ISO 8434-1.
- NPTF (Dryseal): Dryseal taper pipe thread, cut so the crests and roots close up as the joint is tightened, so it seals on the thread; ASME B1.20.3.
Sizes
11 part numbers, M12×1.5 to M26×1.5. The Sizes & Part Numbers tab lists the size on each end and the tube O.D. for every one.
- End 1: metric 24° cone / port (dual purpose), M12×1.5 to M26×1.5
- End 2: NPTF (Dryseal), 1/4" to 3/4" (1/4-18 to 3/4-14)
Pressure rating
The manufacturer publishes no pressure rating for this family. Tell us the working pressure your line sees and we will confirm the fitting is rated for it before you order.
How to order
Quote the Indus part number from the size table. If you only have the fitting, send the thread or tube size on each end, and Indus engineering will confirm the part number. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Body Configuration | straight adapter |
Port A
| Parameter | Value |
|---|---|
| Port A Thread | metric 24° cone / port (dual purpose), M12×1.5 to M26×1.5 |
| Port A Sealing | dual-purpose metric end: takes a DIN 2353 24° tube nut and cutting ring, or screws into a metric port |
| Port A Gender | male |
Port B
| Parameter | Value |
|---|---|
| Port B Thread | NPTF (Dryseal), 1/4" to 3/4" (1/4-18 to 3/4-14) |
| Port B Sealing | Dryseal taper pipe thread, cut so the crests and roots close up as the joint is tightened, so it seals on the thread |
| Port B Gender | female |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | M12×1.5 to M26×1.5 |
Construction
| Parameter | Value |
|---|---|
| Material | forged carbon steel, trivalent zinc plated |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | DIN 2353, ISO 8434-1, ASME B1.20.3 |
Shipping & lead time
Sizes & part numbers
11 sizes| Indus part no. | End 1 | End 2 | Tube O.D. (mm) |
|---|---|---|---|
| IH-ST-9635S-12-L06-04 | M12×1.5 (6 mm tube, L series) | 1/4" NPTF (1/4-18) | 6 |
| IH-ST-9635S-12-L06-06 | M12×1.5 (6 mm tube, L series) | 3/8" NPTF (3/8-18) | 6 |
| IH-ST-9635S-14-L08-04 | M14×1.5 (8 mm tube, L series) | 1/4" NPTF (1/4-18) | 8 |
| IH-ST-9635S-16-L10-04 | M16×1.5 (10 mm tube, L series) | 1/4" NPTF (1/4-18) | 10 |
| IH-ST-9635S-16-L10-06 | M16×1.5 (10 mm tube, L series) | 3/8" NPTF (3/8-18) | 10 |
| IH-ST-9635S-18-L12-04 | M18×1.5 (12 mm tube, L series) | 1/4" NPTF (1/4-18) | 12 |
| IH-ST-9635S-18-L12-06 | M18×1.5 (12 mm tube, L series) | 3/8" NPTF (3/8-18) | 12 |
| IH-ST-9635S-18-L12-08 | M18×1.5 (12 mm tube, L series) | 1/2" NPTF (1/2-14) | 12 |
| IH-ST-9635S-22-L15-08 | M22×1.5 (15 mm tube, L series) | 1/2" NPTF (1/2-14) | 15 |
| IH-ST-9635S-22-L15-12 | M22×1.5 (15 mm tube, L series) | 3/4" NPTF (3/4-14) | 15 |
| IH-ST-9635S-26-L18-12 | M26×1.5 (18 mm tube, L series) | 3/4" NPTF (3/4-14) | 18 |
End 1 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. End 2 — Thread or flange nominal size at this end, exactly as the manufacturer prints it. Tube O.D. — Outside diameter of the tube the port is cut for. Ask us for the dimension drawing if you need it stamped.
Every size is available in 316 stainless steel on request — add “-SS” to the part number when you enquire.
