Square Fender

Square Fender, in 8 sizes. Indus part numbers.
Key features
- Product type: Square Fender
- Material
- Rubber
Product description
Rubber marine fenders and dock bumpers for berths, jetties and tugs. Rubber.
Sizes
8 sizes. Every size has its own Indus part number in the table below.
The lettered dimensions in the table refer to the dimension drawing shown with this product.
Manufacturer's data
- Molded pressing.
Choosing a size
Size a fender on the berthing energy it must absorb and the reaction the hull and structure can take; send vessel and berth details for a selection.
Ordering
Quote the Indus part number from the size table, or send the size and rating you need.
Identification
| Parameter | Value |
|---|---|
| Product type | Square Fender |
| Sizes | 8 |
Construction
| Parameter | Value |
|---|---|
| Material | Rubber |
Shipping & lead time
Sizes & part numbers
8 sizes- Indus part no.IH-LR-MF-SF-SD100
- Size
- SD100
- A (mm)
- 100
- B (mm)
- 100
- C (mm)
- 50
- D (mm)
- 45
- ØE (mm)
- 30
- ØF (mm)
- 15
- Weight (kg)
- 10.5
- Indus part no.IH-LR-MF-SF-SD150
- Size
- SD150
- A (mm)
- 150
- B (mm)
- 150
- C (mm)
- 70
- D (mm)
- 65
- ØE (mm)
- 40
- ØF (mm)
- 20
- Weight (kg)
- 24
- Indus part no.IH-LR-MF-SF-SD200
- Size
- SD200
- A (mm)
- 200
- B (mm)
- 200
- C (mm)
- 90
- D (mm)
- 95
- ØE (mm)
- 60
- ØF (mm)
- 30
- Weight (kg)
- 42
- Indus part no.IH-LR-MF-SF-SD250
- Size
- SD250
- A (mm)
- 250
- B (mm)
- 250
- C (mm)
- 120
- D (mm)
- 120
- ØE (mm)
- 65
- ØF (mm)
- 33
- Weight (kg)
- 65
- Indus part no.IH-LR-MF-SF-SD300
- Size
- SD300
- A (mm)
- 300
- B (mm)
- 300
- C (mm)
- 125
- D (mm)
- 135
- ØE (mm)
- 65
- ØF (mm)
- 35
- Weight (kg)
- 97
- Indus part no.IH-LR-MF-SF-SD350
- Size
- SD350
- A (mm)
- 350
- B (mm)
- 350
- C (mm)
- 175
- D (mm)
- 175
- ØE (mm)
- 80
- ØF (mm)
- 38
- Weight (kg)
- 124
- Indus part no.IH-LR-MF-SF-SD400
- Size
- SD400
- A (mm)
- 400
- B (mm)
- 400
- C (mm)
- 200
- D (mm)
- 200
- ØE (mm)
- 80
- ØF (mm)
- 40
- Weight (kg)
- 162
- Indus part no.IH-LR-MF-SF-SD500
- Size
- SD500
- A (mm)
- 500
- B (mm)
- 500
- C (mm)
- 250
- D (mm)
- 250
- ØE (mm)
- 95
- ØF (mm)
- 46
- Weight (kg)
- 252
Size — Nominal size as the manufacturer states it. A — Dimension A on the manufacturer dimension drawing. B — Dimension B on the manufacturer dimension drawing. C — Dimension C on the manufacturer dimension drawing. D — Dimension D on the manufacturer dimension drawing. ØE — Dimension ØE on the manufacturer dimension drawing. ØF — Dimension ØF on the manufacturer dimension drawing. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What is the square fender and what sizes does it come in?▾
How do I read the Indus part number on the square fender?▾
What dimensions does the square fender table list?▾
How do I size a square fender for a berth?▾
What energy absorption and reaction force does the square fender have?▾
What is the square fender made of?▾
Which standard or certificate applies to the square fender?▾
What do I mount the square fender with, and what goes beside it?▾
How does energy absorption differ from reaction force on a square fender?▾
Where is the square fender used?▾
Square fender compared with the D type fender?▾
Do you stock the square fender, and how do I order?▾
