Arch Fender DA Type

Arch Fender DA Type, in 9 sizes. Indus part numbers.
Key features
- Product type: Arch Fender DA Type
Product description
Rubber marine fenders and dock bumpers for berths, jetties and tugs.
Sizes
9 sizes. Every size has its own Indus part number in the table below.
The lettered dimensions in the table refer to the dimension drawing shown with this product.
Choosing a size
Size a fender on the berthing energy it must absorb and the reaction the hull and structure can take; send vessel and berth details for a selection.
Ordering
Quote the Indus part number from the size table, or send the size and rating you need.
Identification
| Parameter | Value |
|---|---|
| Product type | Arch Fender DA Type |
| Sizes | 9 |
Shipping & lead time
Sizes & part numbers
9 sizes- Indus part no.IH-LR-MF-AFDA-150H
- Size
- 150H
- B (mm)
- 240
- C (mm)
- 96
- D (mm)
- 22
- F (mm)
- 98
- G (mm)
- 95
- H (mm)
- 150
- M (mm)
- 55
- P (mm)
- 25
- W (mm)
- 300
- Q (mm)
- 50
- Indus part no.IH-LR-MF-AFDA-200H
- Size
- 200H
- B (mm)
- 320
- C (mm)
- 128
- D (mm)
- 24
- F (mm)
- 150
- G (mm)
- 105
- H (mm)
- 200
- M (mm)
- 75
- P (mm)
- 29
- W (mm)
- 400
- Q (mm)
- 58
- Indus part no.IH-LR-MF-AFDA-250H
- Size
- 250H
- B (mm)
- 410
- C (mm)
- 160
- D (mm)
- 30
- F (mm)
- 187
- G (mm)
- 125
- H (mm)
- 250
- M (mm)
- 90
- P (mm)
- 32
- W (mm)
- 500
- Q (mm)
- 64
- Indus part no.IH-LR-MF-AFDA-300H
- Size
- 300H
- B (mm)
- 490
- C (mm)
- 195
- D (mm)
- 33
- F (mm)
- 225
- G (mm)
- 140
- H (mm)
- 300
- M (mm)
- 105
- P (mm)
- 35
- W (mm)
- 600
- Q (mm)
- 70
- Indus part no.IH-LR-MF-AFDA-400H
- Size
- 400H
- B (mm)
- 670
- C (mm)
- 260
- D (mm)
- 40
- F (mm)
- 300
- G (mm)
- 165
- H (mm)
- 400
- M (mm)
- 120
- P (mm)
- 41
- W (mm)
- 800
- Q (mm)
- 82
- Indus part no.IH-LR-MF-AFDA-500H
- Size
- 500H
- B (mm)
- 840
- C (mm)
- 325
- D (mm)
- 45
- F (mm)
- 375
- G (mm)
- 180
- H (mm)
- 500
- M (mm)
- 140
- P (mm)
- 47
- W (mm)
- 1,000
- Q (mm)
- 94
- Indus part no.IH-LR-MF-AFDA-600H
- Size
- 600H
- B (mm)
- 1,010
- C (mm)
- 390
- D (mm)
- 54
- F (mm)
- 450
- G (mm)
- 195
- H (mm)
- 600
- M (mm)
- 160
- P (mm)
- 50
- W (mm)
- 1,200
- Q (mm)
- 100
- Indus part no.IH-LR-MF-AFDA-800H
- Size
- 800H
- B (mm)
- 1,340
- C (mm)
- 520
- D (mm)
- 72
- F (mm)
- 600
- G (mm)
- 270
- H (mm)
- 800
- M (mm)
- 260
- P (mm)
- 68
- W (mm)
- 1,600
- Q (mm)
- 136
Show all 9 sizesShow fewer sizes
- Indus part no.IH-LR-MF-AFDA-1000H
- Size
- 1000H
- B (mm)
- 1,550
- C (mm)
- 580
- D (mm)
- 52
- F (mm)
- 650
- G (mm)
- 290
- H (mm)
- 1,000
- M (mm)
- 300
- P (mm)
- 54
- W (mm)
- 1,850
- Q (mm)
- 108
Size — Nominal size as the manufacturer states it. B — Dimension B on the manufacturer dimension drawing. C — Dimension C on the manufacturer dimension drawing. D — Dimension D on the manufacturer dimension drawing. F — Dimension F on the manufacturer dimension drawing. G — Dimension G on the manufacturer dimension drawing. H — Dimension H on the manufacturer dimension drawing. M — Dimension M on the manufacturer dimension drawing. P — Dimension P on the manufacturer dimension drawing. W — Dimension W on the manufacturer dimension drawing. Q — Dimension Q on the manufacturer dimension drawing. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
