Silicone Suction & Delivery Hose
For use in Pharmaceutical, food & beverage applications in health and personal care industries
Key features
- Application Family: food-beverage
- Manufacturer Part Code: SANSIL
- Inner Diameter Range: 13 mm to 102 mm
- Max Working Pressure: 3-10 bar
- Operating Temperature: From -40°C to +200°C
- Application Family
- food-beverage
- Manufacturer Part Code
- SANSIL
- Inner Diameter Range
- 13 mm to 102 mm
- Max Working Pressure
- 3-10 bar
- Operating Temperature
- From -40°C to +200°C
Product description
The Silicone Suction & Delivery Hose (part code SANSIL) is a Food & Beverage Hose from the Indus Hydraulics industrial hose range.
Application
For use in Pharmaceutical, food & beverage applications in health and personal care industries
Construction
- Cover: Translucent seamless extruded silicone, Platinum cured
- Lining / Tube: FDA approved transparent seamless smooth silicone, Platinum cured
- Reinforcement: Polyester fabrics, 316L stainless steel helix
- Branding (printed on hose): Refer to host hose marking
Performance
- Inner-diameter range: 13 mm to 102 mm
- Max working pressure: 3-10 bar
- Min burst pressure: 12-40 bar
- Min bend radius: 45-360 mm
- Weight: 0.39-3.99 kg/m
- Operating temperature: From -40°C to +200°C
- Safety factor: 4:1
Family context
FDA / EU food-grade hoses for hygienic transfer of beverages, dairy, and bulk food ingredients. Hygienic San-grade NBR, silicone, and PVC tube options. CIP/SIP cleaning compatible.
How to order
Specify (a) the inner diameter from the size range, (b) the assembly length, (c) end-fitting requirements, and (d) any special requirements such as Lloyd's certification or third-party witness testing. Indus engineering will confirm the assembly drawing on the RFQ.
Companion products
Pair with matching couplings and accessories (Cam & Groove, Boss steam couplings, hose clamps, Holedall permanently-attached fittings, hose tags, and Spiral Hose Guard / Fire Jacket protective sleeves) — full range available on quote.
Identification
| Parameter | Value |
|---|---|
| Application Family | food-beverage |
| Manufacturer Part Code | SANSIL |
| Hose Branding (Printed) | Refer to host hose marking |
Dimensions
| Parameter | Value |
|---|---|
| Inner Diameter Range | 13 mm to 102 mm |
| Min Bend Radius | 45-360 mm |
| Weight | 0.39-3.99 kg/m |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | 3-10 bar |
| Min Burst Pressure | 12-40 bar |
| Operating Temperature | From -40°C to +200°C |
| Safety Factor | 4:1 |
Construction
| Parameter | Value |
|---|---|
| Cover Material | Translucent seamless extruded silicone, Platinum cured |
| Lining / Tube Material | FDA approved transparent seamless smooth silicone, Platinum cured |
| Reinforcement | Polyester fabrics, 316L stainless steel helix |
Shipping & lead time
Sizes & part numbers
9 sizes| Indus part no. | Hose bore | O.D. (mm) | Min burst (bar) | Min bend radius (mm) | Weight (kg/m) | Working pressure (bar) |
|---|---|---|---|---|---|---|
| IH-IH-SANSIL-013 | 1/2" · DN13 | 25 | 40 | 45 | 0.39 | 10 |
| IH-IH-SANSIL-019 | 3/4" · DN19 | 31 | 40 | 65 | 0.63 | 10 |
| IH-IH-SANSIL-025 | 1" · DN25 | 38 | 40 | 80 | 0.84 | 10 |
| IH-IH-SANSIL-032 | 1-1/4" · DN32 | 44 | 40 | 120 | 0.99 | 10 |
| IH-IH-SANSIL-038 | 1-1/2" · DN38 | 51 | 40 | 150 | 1.38 | 10 |
| IH-IH-SANSIL-051 | 2" · DN51 | 63 | 40 | 180 | 1.87 | 10 |
| IH-IH-SANSIL-063 | 2-1/2" · DN63 | 76 | 28 | 220 | 2.23 | 7 |
| IH-IH-SANSIL-076 | 3" · DN76 | 89 | 16 | 250 | 2.98 | 4 |
| IH-IH-SANSIL-102 | 4" · DN102 | 114 | 12 | 360 | 3.99 | 3 |
O.D. — Outside diameter of the hose, which is what a clamp or a ferrule has to close on. Min burst — Minimum burst pressure. A test figure, never a working limit — never select on it. Min bend radius — Tightest centreline radius the hose may be bent to at full working pressure. Weight — Weight of the hose per metre, as published.
Working pressure is the published rating for the hose itself. A made-up assembly is limited by its lowest-rated part, so check it against the coupling, the clamp or ferrule, and the temperature you are running at.
Cut lengths and made-up assemblies are prepared in Dubai. Tell us the bore, the length and the ends you need.
What is this hose used for?▾
What sizes are available?▾
What is the maximum working pressure?▾
What is the operating temperature range?▾
What is the construction (cover / lining / reinforcement)?▾
What is the printed branding on the hose?▾
Lead time?▾
Shipped worldwide from our Dubai warehouse. Transit, routes and documentation for 126 destinations
