Light Snatch Block with Hook — 418 Pattern, 2–15 t WLL

Light Snatch Block with Hook, 418 pattern, in 9 sizes, 3″ to 18″, WLL 2 to 15 t. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Light Snatch Block with Hook
- Pattern / standard: 418
- Size range: 3″ to 18″
- Working load limit: 2 to 15 t
- Size range
- 3″ to 18″
- Working load limit
- 2 to 15 t
Product description
Snatch blocks and pulley blocks change the direction of a rope or multiply a line pull. This range follows the 418 pattern.
Sizes and ratings
9 sizes, 3″ to 18″. Working load limit 2 to 15 t. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Rate the block for the load it actually sees: with the rope turned through 180° it carries about twice the line pull. Match the sheave to the rope diameter.
Ordering
Quote the Indus part number from the size table, or send the size and working load you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Light Snatch Block with Hook |
| Pattern / standard | 418 |
| Sizes | 9 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 3″ to 18″ |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 2 to 15 t |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
9 sizesReplaces the Crosby 418 series. Quote the Indus part number, or send us the Crosby number and we will cross it.
- Indus part no.IH-LR-BP-418-300
- Size
- 3″
- Rope size
- 3/8″
- WLL (t)
- 2
- Weight (kg)
- 2.3
- Indus part no.IH-LR-BP-418-450
- Size
- 4-1/2″
- Rope size
- 1/2″
- WLL (t)
- 4
- Weight (kg)
- 5.74
- Indus part no.IH-LR-BP-418-600
- Size
- 6″
- Rope size
- 3/4″
- WLL (t)
- 8
- Weight (kg)
- 11.5
- Indus part no.IH-LR-BP-418-800
- Size
- 8″
- Rope size
- 3/4″
- WLL (t)
- 8
- Weight (kg)
- 15.75
- Indus part no.IH-LR-BP-418-1000
- Size
- 10″
- Rope size
- 3/4″
- WLL (t)
- 8
- Weight (kg)
- 21.9
- Indus part no.IH-LR-BP-418-1200
- Size
- 12″
- Rope size
- 3/4″
- WLL (t)
- 8
- Weight (kg)
- 30
- Indus part no.IH-LR-BP-418-1400
- Size
- 14″
- Rope size
- 3/4″
- WLL (t)
- 8
- Weight (kg)
- 36
- Indus part no.IH-LR-BP-418-1600
- Size
- 16″
- Rope size
- 7/8″
- WLL (t)
- 15
- Weight (kg)
- 99
Show all 9 sizesShow fewer sizes
- Indus part no.IH-LR-BP-418-1800
- Size
- 18″
- Rope size
- 1″
- WLL (t)
- 15
- Weight (kg)
- 112.5
Size — Nominal size as the manufacturer states it. Rope size — Rope diameter the sheave is made for. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
Indus Hydraulics is not affiliated with Crosby. Crosby part numbers are shown for cross-reference only, so you can order from an existing bill of materials.
The following competitor part numbers are compatible with or superseded by this SKU. Click through to the dedicated replacement page for each.
What is the Light Snatch Block with Hook — 418 Pattern and what is it used for?▾
What sizes does the Light Snatch Block with Hook — 418 Pattern come in?▾
How do I size the Light Snatch Block with Hook — 418 Pattern for a job?▾
What WLL does the Light Snatch Block with Hook — 418 Pattern carry?▾
How do I order a specific size of the Light Snatch Block with Hook — 418 Pattern?▾
Is the Light Snatch Block with Hook — 418 Pattern equivalent to the Crosby 418 pattern?▾
What is the Light Snatch Block with Hook — 418 Pattern made of?▾
Which standard does the Light Snatch Block with Hook — 418 Pattern meet?▾
What does the Light Snatch Block with Hook — 418 Pattern connect with?▾
How do I inspect the Light Snatch Block with Hook — 418 Pattern before use?▾
Where is the Light Snatch Block with Hook — 418 Pattern typically used?▾
Does Indus stock the Light Snatch Block with Hook — 418 Pattern in Dubai?▾
