Double Sheave Pulley Block
Double Sheave Pulley Block, in 10 sizes, 1/2″ to 5″, WLL 50 to 500 kg. Indus part numbers, manufacturer's test certificate.
Key features
- Product type: Double Sheave Pulley Block
- Size range: 1/2″ to 5″
- Working load limit: 50 to 500 kg
- Size range
- 1/2″ to 5″
- Working load limit
- 50 to 500 kg
Product description
Snatch blocks and pulley blocks change the direction of a rope or multiply a line pull.
Sizes and ratings
10 sizes, 1/2″ to 5″. Working load limit 50 to 500 kg. Every size has its own Indus part number in the table below, with the loads in the unit the manufacturer rates them in.
Choosing a size
Rate the block for the load it actually sees: with the rope turned through 180° it carries about twice the line pull. Match the sheave to the rope diameter.
Ordering
Quote the Indus part number from the size table, or send the size and working load you need. Each consignment ships with the manufacturer's test certificate; say on the RFQ if your site needs anything more.
Identification
| Parameter | Value |
|---|---|
| Product type | Double Sheave Pulley Block |
| Sizes | 10 |
Dimensions
| Parameter | Value |
|---|---|
| Size range | 1/2″ to 5″ |
Performance
| Parameter | Value |
|---|---|
| Working load limit | 50 to 500 kg |
Compliance
| Parameter | Value |
|---|---|
| Certification | Manufacturer's test certificate |
Shipping & lead time
Sizes & part numbers
10 sizes| Indus part no. | Size | Rope size | WLL (kg) | Weight (kg) |
|---|---|---|---|---|
| IH-LR-BP-DSP-050 | 1/2″ | 5/32″ | 50 | 0.04 |
| IH-LR-BP-DSP-075 | 3/4″ | 3/16″ | 75 | 0.06 |
| IH-LR-BP-DSP-100 | 1″ | 1/4″ | 100 | 0.09 |
| IH-LR-BP-DSP-125 | 1-1/4″ | 5/16″ | 150 | 0.15 |
| IH-LR-BP-DSP-150 | 1-1/2″ | 5/16″ | 250 | 0.225 |
| IH-LR-BP-DSP-200 | 2″ | 7/16″ | 300 | 0.4 |
| IH-LR-BP-DSP-250 | 2-1/2″ | 1/2″ | 350 | 0.71 |
| IH-LR-BP-DSP-300 | 3″ | 5/8″ | 400 | 1.16 |
| IH-LR-BP-DSP-400 | 4″ | 3/4″ | 450 | 2.7 |
| IH-LR-BP-DSP-500 | 5″ | 3/4″ | 500 | 4.6 |
Size — Nominal size as the manufacturer states it. Rope size — Rope diameter the sheave is made for. WLL — Working load limit — the most the part may carry in service, as the manufacturer rates it. Weight — Weight as the manufacturer publishes it. Ask us for the dimension drawing if you need it stamped.
WLL is the most the part may carry in service. Proof and breaking loads are test figures — never lift to them. Each load is shown in the unit the manufacturer rates the part in, and a size ships with the manufacturer’s test certificate.
What sizes does the double sheave pulley block come in?▾
What is the working load limit?▾
Can a snatch block be used for lifting?▾
Do the parts come with a test certificate?▾
