45° JIC Male 74° Cone — JIC adapter, 45 elbow body, 7 orderable sizes on this page. RFQ-only; standard Indus zinc-plated carbon-steel construction.
Key features
- Body Configuration: 45 elbow
- Port A Thread: UN/UNF 7/16-20 to 1.5/16-12
- Port A Sealing: JIC 37° cone (74° included)
- Nominal Size Range: -04 to -16
- Max Working Pressure: up to 345 bar (5,004 psi), manufacturer stated
- Body Configuration
- 45 elbow
- Port A Thread
- UN/UNF 7/16-20 to 1.5/16-12
- Port A Sealing
- JIC 37° cone (74° included)
- Nominal Size Range
- -04 to -16
- Max Working Pressure
- up to 345 bar (5,004 psi), manufacturer stated
Product description
The 45° JIC Male 74° Cone is a 45 elbow hydraulic adapter in the Indus JIC range. Every size the manufacturer publishes is listed in the Sizes & Part Numbers tab, with the thread on each end, the dimensions, the weight and the working pressure.
Construction
- Body configuration: 45 elbow
- Port A: 45° JIC Male 74° Cone
- Material: carbon steel (stainless steel available on request)
- Surface treatment: zinc-plated, Cr3+ passivated, RoHS-compliant
Threads
- Port A: UN/UNF 7/16-20 to 1.5/16-12
- Port B: UN/UNF 7/16-20 to 1.5/16-12
Sealing
JIC 37° cone (74° included). Match the seat as well as the thread — a thread that engages against the wrong seat will weep under pressure, and several of these families share a thread while sealing differently.
Performance
The manufacturer states 210 to 345 bar depending on size, printed against every size in the table. That is the rating of the adapter; an assembly is limited by whichever component is rated lowest — the hose, the tube or the port.
Applicable standards
SAE J514, ISO 8434-2.
How to order
Quote the Indus part number from the size table. If you have only the ports, send us the thread on each end and whether you need carbon steel or stainless, and Indus engineering will confirm the part number against your equipment.
Companion products
These are tube and port adapters, not hose ends. For hose assemblies pair them with Indus crimp ferrules and the matching hose-end fitting; for tube runs, with Indus cutting rings and end nuts.
Identification
| Parameter | Value |
|---|---|
| Body Configuration | 45 elbow |
Port A
| Parameter | Value |
|---|---|
| Port A Thread | UN/UNF 7/16-20 to 1.5/16-12 |
| Port A Sealing | JIC 37° cone (74° included) |
| Port A Gender | male |
Port B
| Parameter | Value |
|---|---|
| Port B Thread | UN/UNF 7/16-20 to 1.5/16-12 |
| Port B Sealing | JIC 37° cone (74° included) |
| Port B Gender | male |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | -04 to -16 |
Performance
| Parameter | Value |
|---|---|
| Max Working Pressure | up to 345 bar (5,004 psi), manufacturer stated |
Construction
| Parameter | Value |
|---|---|
| Material | Carbon steel (stainless on request) |
| Surface Treatment | Zinc-plated, Cr3+ passivated, RoHS-compliant |
Compliance
| Parameter | Value |
|---|---|
| Applicable Standards | SAE J514, ISO 8434-2 |
Shipping & lead time
The same part, in the designations used across European and Gulf trade catalogues.
- de
- 45° Bogen JIC Außengewinde 37° Bördel
- fr
- mâle coude 45° JIC cône 37°
- es
- macho JIC codo 45° cono 37°
- it
- maschio gomito 45° JIC cono 37°
