Parker 1TU56 CPI Compression Crimp Fitting, Straight (56 Series)
Parker 1TU56 56 Series crimp hose fitting — CPI Compression, straight, for thermoplastic hose. 2 sizes, hose -4 to -6, steel.
Key features
- Fitting Configuration: Straight
- Nominal Size Range: Hose -4 to -6, end -4 to -6
- Series
- Parker 56 Series
- Fitting Configuration
- Straight
- End Connection
- CPI Compression
Product description
The Parker 1TU56 is a 56 Series permanent (crimp) hose fitting: CPI Compression, straight. Parker lists the 56 Series for Parker (Parflex) thermoplastic hoses.
Specification
- Series: Parker 56 (thermoplastic hose)
- End connection: CPI Compression
- Form: Straight
- Material: Steel
- Hose bore: -4 to -6 (1/4" to 3/8")
- End sizes: -4 to -6
Sizes and part numbers
2 Parker part numbers — the Sizes & Part Numbers tab lists each with its end thread and hose bore. Parker numbers read style and series, then end size, then hose size: 1TU56-4-4 is a -4 end on -4 (1/4") hose.
Assembly
Crimp the fitting only onto a hose Parker approves for the series, using the crimper and die setting Parker publishes for that fitting and hose. Do not mix fittings and hose from different series or makers in one assembly; the assembly is only rated as a matched combination.
How to order
Quote the Parker part number, or send the end connection, end size and hose. Price and lead time are confirmed with the quotation.
Identification
| Parameter | Value |
|---|---|
| Series | Parker 56 Series |
| Fitting Configuration | Straight |
| End Connection | CPI Compression |
Dimensions
| Parameter | Value |
|---|---|
| Nominal Size Range | Hose -4 to -6, end -4 to -6 |
Construction
| Parameter | Value |
|---|---|
| Material | Steel |
Compatibility
| Parameter | Value |
|---|---|
| Hose Compatibility | Parker (Parflex) thermoplastic hoses |
| Assembly | permanent crimp |
Shipping & lead time
Sizes & part numbers
2 sizes| Parker Hannifin part no. | Hose bore | Thread |
|---|---|---|
| 1TU56-4-4 | -04 · 1/4" | -4 (1/4") |
| 1TU56-6-6 | -06 · 3/8" | -6 (3/8") |
Which hoses does the Parker 56 Series fit?▾
How do I read the part number 1TU56-4-4?▾
Can I crimp it onto another make of hose?▾
What is the lead time?▾
